Stiebel Eltron Stiebel WPE WPM Extension Accessories

Stiebel Eltron Expansion Control WPE

Manufacturer: Stiebel Eltron
Designation: Expansion Control 0-10V Interface
Type: WPE
Number of Mixing Groups: 2
Drinking Water Regulation: yes
Boiler Switching Valve Regulation: no
Split Unit Control: no
Swimming Pool Control: yes
Heat Pump Control: yes
Supply Voltage: 230 V
With Display: no
Communication Bus: other
Communication Protocol: other
Suitable for Wall Mounting: yes
Self-Operating: no
Protection Class (IP): IP21
Height: 400 mm
Width: 310 mm
Depth: 100 mm

The WPE expands the Heat Pump Manager WPM with numerous functions. It offers two additional mixed heating circuits, a swimming pool controller, and a cascade control for up to six heat pumps. Additionally, there are two extra 0-10 V interfaces, a differential controller, and switching outputs available. The housing is installed to the right or left of the WPM and connected to it for power supply and via the bus. The additional functions of the module can be set at the WPM control unit.
EAN: 4017212347256.
