Schell Shower panel LINUS DP-C-T Shower head COMFORT Alu-anodised

Ratings
BrandMore from Schell
Delivered between Sat, 3.10. and Tue, 3.11.
free shipping

Colour5

Show all

Product details

CVD touch electronics - battery/mains operation - on/off/time-limit thermostatic stagnation flush - panel made of aluminium - easy to install and service thanks to swivelling front shell - suitable for connections from behind or for pre-wall connections from above.

Scope of delivery: panel with pre-mounted LINUS shower fitting with integrated solenoid valve 6 V and thermostatic cartridge including piping between fitting and shower head connection - splash-proof touch electronics - thermostatic cartridge with safety lock in case of cold water failure - actuating knob thermostatic valve with hot water lock 38 °C - locking disc for maximum temperature limitation (scald protection) - 2x backflow preventer - shower head flow rate 9 l/min pressure-independent - fixing material - connection accessories.

Further technical features:

  • Flow connection: External thread
  • Supply connection: 1/2 inch
  • Temperature control type: thermostatic
  • Automatic rinsing cycle: Yes
  • Shower operation: electronic
  • Min. pressure: 1 bar
  • Min. flow rate (mixed water): 15 l/min
  • With fixing material: Yes
  • With overhead shower: No
  • With backflow protection: Yes
  • With change-over unit: Yes
  • Mounting: Wall
  • Self-closing: Yes
  • Depth: 115 mm
  • Anti-scald protection: Yes
  • Material: Aluminium
  • Max. pressure: 5 bar.

Key specifications

Connection thread
0.50"
mounting style
Face

General information

Item number
24193946
Manufacturer
Schell
Category
Shower systems
Manufacturer No.
008190899
Release date
20.2.2023

Colour

Colour
Silver
Exact colour description
Anodised aluminium, Chromed

Material

Material group
Metal
Material
Aluminium

Shower system properties

Connection thread
0.50"
Flow pressure
1 bar
Max. Flow rate at 3 bar
9 l/min
Additional properties
Thermostat

Shower head features

water usage
9 l/min

Hand shower features

water usage
9 l/min
Additional functions
Anti-lime knobs

Mounting

mounting style
Face

Safety

Safety lock at
38 °C

Voluntary climate contribution

CO₂ emissions
31.77 kg
Climate contribution
CHF 0.76

Scope of delivery

Scope of delivery
Hand shower, Head shower, Shower hose

Product dimensions

Width
22.60 cm
Height
120 cm
