Schuch SCHU LED Mast Light

LED outdoor light VIA, 24 W, 106 W, 4190 lm, 16730 lm, SKII, IP66, asymmetrical wide beam, 4000 K, Ra= 70, Ta -40 °C/+25 °C, L90>100000 h (@ Ta max), clear safety glass, aluminum die-cast housing, painted, color gray, DB 702, variable and nearly stepless adjustable luminous flux (Note: Only min, max values are provided).

The VIA LED outdoor light from the GreenLine series features an outstandingly sustainable product design with variable adjustable luminous flux. It has a two-part, powder-coated aluminum die-cast housing that is hinged and equipped with a safety bracket.

The LED modules and the electronic ballast are mounted on tool-free removable carrier plates in the upper part of the housing. Cable entry is provided with a screw connection and strain relief, plug-in connection, and pressure equalization system in the lower part of the housing. The flat safety glass, silicone gasket, and central locking made of aluminum provide additional safety.

The Zhaga-compliant LED modules are equipped with highly efficient optics and utilize a direct emitting multi-layer technology. The electronic ballast offers high surge voltage resistance as well as overload and short-circuit protection.

A universal mast adapter made of aluminum die-cast is suitable for mast diameters of 60/76 for mast base or mast top mounting. For a mast diameter of 42, separate reducing accessories are required. The tilt adjustment is 0°, 5°, 10°, 15° for top mounting and 0°, -5°, -10°, -15° for base mounting, with scaling on the luminaire housing.
