Best Omron Industrial Automation products in the Mobile power distributors category

On this page you'll find a ranking of the best Omron Industrial Automation products in this category. To give you a quick overview, we've already ranked the most important information about the products for you.

1. Omron Industrial Automation Limit switch

Actuator type: Roller lever
Actuator included: Yes
Contact configuration: Normally open / Normally closed
Switching function: Snap action
Protection class: IP67
Connection type: Screw fixing
Number of contacts: 2
Number and position of contacts: 1-pole changeover contact
Series: D4N
Number of cable entries: 1

This D4N series safety limit switch is TÜV EN60947-5-1 approved for direct opening, and complies with UL508, CSA C22.2 No. 14, CCC (CQC) GB14048.5, EN50047, and EN1088 (slow action models only). It serves as a replacement for the Omron D4D-N series limit switch. While the functionality remains unchanged, the housing length has increased by 4 mm, which does not affect the position of the actuator. It features an NC contact for the safety circuit and an NO contact for the control circuit (1-pole changeover switch). The contact rating is 10 A continuous. The head can be positioned in 4 different orientations as needed. The protection class is IP67, and the cable entry is PG13.5. The ambient operating temperature ranges from -30 to +70°C. This product complies with the Machinery Directive and the Low Voltage Directive.

2. Omron Industrial Automation S8FSG15015CD

Power supply, Type=S8FSG15015CD, Rated output voltage 1=15 V, Rated output voltage 2=-888, Rated output voltage 3=-888, Output voltage 1=15 V, Output voltage 2=-888, Output voltage 3=-888, Output current 1=10 A, Output current 2=-888, Output current 3=-888, Outputs=1, Operating temperature, max.=70 °C, Operating temperature, min.=-20 °C, Width=39.2 mm, Efficiency=85 %, Input voltage, max.=240 V, Input voltage, min.=100 V, Height=97 mm, Insulation voltage=3 kV, MTBF (Mean Time Between Failures)=135000 h, Rated power=150 W, Rated power (VA)=-999, Depth=197 mm, Ripple & noise (%)=-999, Ripple & noise (V)=80 mV, Connection type=Screw terminal block, Output type=Adjustable, Rated input voltage=100 ... 240 VAC, Conformity to standards=UL Listed CSA UL Recognised CE, Series=S8FS-G.

3. Omron Industrial Automation D4E1D10N

4. Omron Industrial Automation D4F3205D

The D4F3205D from Omron Industrial Automation is a highly advanced limit switch designed for a variety of industrial applications. With an actuation force of 5 N and an insulation voltage of 500 VDC, this limit switch offers reliable performance in demanding environments. The switching voltages reach up to 240 V AC and 250 V DC, while the switching current is 750 mA AC and 270 mA DC. The D4F3205D is equipped with a roller lever that allows for precise actuation. The IP67 protection rating ensures that the switch is dust-tight and protected against temporary immersion in water, making it ideal for use in harsh environments. With a contact configuration of 2 normally closed and 2 normally open contacts, this limit switch provides versatile connection options and flexibility in application.

- IP67 protection rating for high resistance to dust and water
- Contact configuration with 2 normally closed and 2 normally open contacts for versatile applications
- Roller lever actuation for precise control
- Slow contact technology for improved switching performance.

5. Omron Industrial Automation D4B4511N

The D4B4511N from Omron Industrial Automation is a highly advanced system power supply switch designed for a variety of industrial applications. With a robust metal construction and an IP67 protection rating, this switch delivers reliable performance in demanding environments. The D4B4511N features a roller lever that allows for precise actuation. The contact configuration includes a normally closed and a normally open contact, providing versatile applications in automation technology. With a high insulation voltage of 600 V and switching voltages of up to 400 V AC and 250 V DC, it ensures safe and efficient control of electrical loads. With a rated current of 10 A, this switch is ideal for applications requiring a reliable power supply.

- IP67 protection rating for use in harsh environments
- Robust metal construction for durability
- Roller lever for precise actuation
- High insulation voltage of 600 V.

6. Omron Industrial Automation Limit switch, variable rod lever.DPDB

Actuator type: Coil spring
Contact number and position: SPST
Contact configuration: Normally open / normally closed
Protection class: IP65
Current max: 5 A AC, 400 mA DC
AC voltage max: 250 V
DC voltage max: 250 V
Connection type: Screw fixing
Contact type: Snap action
Mounting position: Rear, front

HL Series miniature limit switch. Unique head structure provides large operating travel for smooth operation. Easy to wire cable channel opening. Ideal for use in printing presses, molding machines, and light machinery.

7. Omron Industrial Automation D4B4A70N

8. Omron Industrial Automation D4B4A16N

9. Omron Industrial Automation D4B4115N

Omron Industrial Automation limit switch, roller lever, metal, 1 NO/1 NC, snap action contact (D4B-4115N).

10. Omron Industrial Automation Enclosed switch,short hinge roller lever

Actuator type: Roller lever
Contact number and position: 1-pole changeover contact
Contact configuration: Normally open/normally closed contact
Protection class: IP67
Current max: 3 A AC, 250 mA DC
AC voltage max: 480 V
DC voltage max: 250 V
Connection type: Screw fixing
Contact type: Snap action
Length: 70 mm
Width: 48.5 mm
Dimensions: 70 x 48.5 x 21.7 mm

UL, CSA, and CCC certified. Enclosed switch D4MC. Extremely useful encapsulated switch. Enclosed switch with integrated basic switches for high repeatability and longevity of at least 10 million operations. Built-in versions have the same operating position as the Z basic switch. Suitable for applications requiring higher mechanical strength and protection against dust and dripping water than those with simple switches.
