Stürmer - Holzkraft ASA 143 raw air extractor

Description for milling, planing, and sawing chips (no dust). Significantly reduced dust content due to BIA-tested filter material with a high separation rate. Housing parts and impellers made of high-strength special plastic. Quick-release fasteners for filters and chip bags for hassle-free maintenance. Robust, high-quality design. Easily movable with swivel casters. Low power consumption. The extraction systems comply with dust class L.

Optional accessories: Fine dust filter cartridge with specially treated polyester fleece. Retains the finest particles. High air flow, large filter area. Higher tear resistance and thus longer service life.

Technical data:
Dimensions and weights:
Length (product) approx. 1062 mm
Width/Depth (product) approx. 648 mm
Height (product) approx. 2300 mm
Weight (net) approx. 53 kg
Chip collection volume 175 l
Nominal diameter of the external extraction nozzle inlet 140 mm
Height with filter cartridge 2525 mm

Electrical data:
Connection voltage 400 V
Mains frequency 50 Hz
Efficiency class of the extraction motor IE3
Power of the drive motor 0.75 kW

Filter:
Filter area 2.2 m²

Noise emission:
Sound pressure level max. 78 dB(A)

Airflow:
Nominal airflow 1650 m³/h

Scope of delivery:
System body with mounted fan unit, filter bag/extraction unit, chip bag/extraction unit without extraction hose.
