Oventrop OV line regulating valve Hydrocontrol VFC PN 6 flange GG25 2 measuring valves DN 150

Ratings
Delivered between Fri, 15.8. and Wed, 17.9.

Product details

The OV Strangregulierventil Hydrocontrol VFC PN 6 is a highly functional valve specifically designed for precise flow regulation in heating systems. With a flange connection according to DIN EN 1092-2 and a nominal inner diameter of DN 150, it provides a reliable solution for differential pressure measurement. The valve is equipped with two measuring valves that allow for simple and effective flow determination. The stepless pre-setting ensures that the desired flow values are controllable at all times. The cast iron GG 25 housing guarantees high stability and durability, while the operating height of 285 mm allows for user-friendly handling. The valve is suitable for use in heating water and offers a maximum medium temperature of 150 °C, making it a versatile choice for various applications.

  • Flange connection on both sides according to DIN EN 1092-2
  • Stepless pre-setting with controllable values at any time
  • Cast iron GG 25 housing for high stability
  • Two measuring valves G 1/4" for precise flow measurement
  • Maximum medium temperature of 150 °C for versatile applications.

Key specifications

Area of use
Water conduit
Metal type
Cast iron
Item number
22169332

General information

Manufacturer
Oventrop
Category
Sanitary installation accessories
Manufacturer no.
1062685
Release date
13.9.2022

Material

Material group
Metal
Metal type
Cast iron
Material
Cast iron GG 25 (GJL-250)

Installation accessories Features

Area of use
Water conduit
Connection thread
25 mm

Voluntary climate contribution

CO₂-Emission
Climate contribution

Product dimensions

Diameter
150 mm
