Product details

OBO Bettermann cable gland V-TEC VM L25 SW

Manufacturer: OBO Bettermann
Designation: Cable gland
Type: V-TEC VM L25 SW
Thread type: Metric
Nominal thread size metric/PG: 25
Thread pitch: 1.5 mm
Thread length: 15 mm
Width across flats: 29 mm
Hexagonal corner dimension: 32 mm
Suitable for cable diameter: 9...17 mm
Material: Plastic
Material grade: Polyamide (PA)
Surface protection: Untreated
Halogen-free: Yes
Glass fibre reinforced: No
Protection class (IP): IP68
Impact resistant: No
Colour: Black
Bending protection: No
With locknut: No
Version: Straight
Multiple sealing insert: No
Flat cable gland: No
With strain relief: Yes
Type of seal: Sealing ring
Separable gland: No
Application temperature: -20..65 °C
Explosion-tested design: No
For Ex zone gas: Without
For Ex zone dust: Without

OBO Bettermann cable gland V-TEC VM L25 SW: further details
Cable gland with metric connection thread in cap nut design, for cable junction boxes, enclosures, and distribution cabinets in the private and industrial sectors. With strain relief and integrated sealing lip, tested according to DIN EN 62444. Protection class IP68. Can be used from -20°C to +65°C.

Key specifications

Colour
Black
Cable connection type
Cable gland
Suitable for cable cross-section
9 mm²
Items per sales unit
25x

General information

Item number
33775041
Manufacturer
OBO Bettermann
Category
Cable joints
Manufacturer no.
2022970
Release date
17.5.2023

Colour

Exact colour description
Black
Colour
Black

Material

Material
Polyamide (PA)
Material group
Plastic

Cable connection Properties

Cable connection type
Cable gland
Suitable for cable cross-section
9 mm²
Plug type
Flat

Origin

Country of origin
Hungary

Voluntary climate contribution

CO₂ emissions
0.25 kg
Climate contribution
CHF 0.11

Safety

Protection type (IP code)
IP68

Scope of delivery

Scope of delivery
Cable gland with metric connection thread in cap nut design, Distribution cabinets in the private and industrial sector. With strain relief and integrated sealing lip, for junction boxes, Housing, tested according to DIN EN 62444, protection class IP68. Can be used from -20°C to +65°C.
Items per sales unit
25x

Product dimensions

Length
15 mm
