Kaiser Junction switch box

Kaiser Junction Box 1555-88

Manufacturer: Kaiser
Designation: Junction Box UP
Type: 1555-88
Mounting Type: Flush-mounted
Shape: Round
Design: Device Connection Box
Version: Single
With Rotatable Ring: No
Couplable: Yes
Filling: None
Diameter: 60 mm
Depth: 63 mm
Internal Depth: 61.4 mm
For Number of Device Inserts: 1
Device Attachment: Screws or Expansion
With Screws: No
Housing Entry via Breakout Opening: Yes
Housing Entry via Sealing Membrane: No
Housing Entry via Pipe Socket: Yes
Housing Entry via Step Membrane: No
For Pipe Diameter: 20 mm
Suitable for Cable Diameter: 13.3 mm
Pipe Locking: No
Pipe Locking Optional: No
Rear Entry: No
Number of Entries: 10
Material: Plastic
Halogen-free: Yes
Surface Protection: Untreated
Color: Black
Protection Class (IP): IP2X
Cover Version: None
Transparent Cover: No
Cover Attachment: Screwed
Seal-able: No
Function Preservation: None
With Shielding: Yes
Air-tight: No
Max. Conductor Cross-section: 2.5 mm²
Terminal Fixed Position: No
Light Hook Attachment: No
Socket: Tunnel Socket
Special Application: None
With Partition Wall: No

Kaiser Junction Box 1555-88: Additional Details
Shielded device connection box (1555-88). Shielded device connection box for flush installation. The conductive coating reduces the emission and reception of interference from predominantly electrical alternating fields. Application area: For built-in devices | Depth: 63 mm | Installation Type: Shielded - biological construction.
