Eaton Snap-action switching element

The Eaton spring switch LS-11S/S is a reliable position switch designed for various applications in system power supply. With a robust plastic housing and an IP66/IP67 protection rating, this product offers high resistance to dust and water, making it ideal for use in demanding environments. The spring rod drive allows for precise actuation, while the contact configuration with one normally closed and one normally open contact provides versatile switching options. The switch is rated for currents up to 6 amperes at a nominal voltage of 400 volts and can operate within a temperature range of -25 to 70 °C. Its compact design, with a width of 31 mm, a height of 61 mm, and a length of 33.5 mm, allows for easy integration into existing systems. Thus, the Eaton spring switch is an excellent choice for applications that require reliability and safety.

• Protection class IP66/IP67 for high resistance to environmental influences
• Spring rod drive for precise actuation
• Contact configuration: 1 normally closed and 1 normally open
• Operating temperature range of -25 to 70 °C
• Suitable for rated currents up to 6 A at 400 V.
