Doepke DOEP DFS2-016-2/0,01-A Fi switch 16A 0,01A 2p

Ratings
Delivered between Sat, 16.8. and Tue, 9.9.

Product details

The DOEP DFS2-016-2/0.01-A is a highly advanced residual current circuit breaker (RCCB) designed for use in single-phase networks. With a rated current of 16 A and a residual current sensitivity of 0.01 A, this switch provides effective protection for people, animals, and electrical systems by immediately disconnecting the power supply in the event of dangerous fault currents. The compact design of the device requires only two modular units, making it ideal for applications with limited space. The switch is available in a variety of fault current types and designs and is suitable for monitoring circuits with a rated voltage of 230 V and a frequency of 50 Hz. User-friendly features such as the switching position indicator and the viewing window for labeling stickers facilitate handling and installation. Additionally, the free labeling software allows for easy labeling of the switches.

  • Two-pole residual current circuit breaker for single-phase networks
  • Sensitive to alternating and pulsating direct fault currents (Type A)
  • High short-circuit resistance and compact size
  • Double-deck terminals on both sides for large conductor cross-sections
  • Multifunctional switch knob with three positions: on, off, tripped.

Key specifications

Circuit breaker type
Fault current circuit breaker
Length
69 mm
Width
2 mm
mounting style
Top-hat rail
number of poles
2
Item number
24873292

General information

Manufacturer
Doepke
Category
Residual-current device
Manufacturer no.
09112601
Release date
16.11.2022

Circuit Breaker Features

Circuit breaker type
Fault current circuit breaker
mounting style
Top-hat rail
number of poles
2
Tripping characteristic
A
Rated current
16 A
Rated voltage
253 V
voltage type
AC/DC
Rated insulation voltage Ui
400 V
Residual current (rated differential current)
0.01 A
Protection type (IP code)
IP20

Origin

Country of origin
Germany

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Items per sales unit
1 Piece

Product dimensions

Length
69 mm
Width
2 mm
