Bosch Home Comfort Thermotechnology Wall-mounted storage tank TR5500T 30 EB

Bosch Thermotechnik wall-mounted storage tank TR5500T 30 EB

Manufacturer: Bosch Thermotechnik
Designation: Wall-mounted storage tank
Type: TR5500T 30 EB
Energy efficiency class: B
Energy efficiency class spectrum: A+ to F
Material of casing: Steel
Volume of tank: 30 l
Material of boiler: Steel
Rated output: 3 kW
Supply voltage: 230..400 V
Three-phase version: Yes
Frequency: 50 Hz
Design: Suspended
Base/undermount boiler: No
With night circuit: Yes
Connection to hot water pipe: No
Duo design: No
Suitable for boiling water: No
With water cooler: No
Wall installation: No
Horizontal installation: No
Vertical installation: Yes
With temperature display: No
With temperature limiter: Yes
With circulation connection: No
Max. pressure: 5 bar
With tap: No
With pressure reducing valve: No
With thermometer: No
With cleaning opening: Yes
Protective anode: Yes
Height: 655 mm
Width: 440 mm
Depth: 470 mm
Nominal diameter cold drinking water: 1/2 inch (15)
Hot water connection: External thread
Nominal diameter hot water connection: 1/2 inch (15)
Protection class (IP): IP25
Energy efficiency hot water: 35 %
Tapping profile: S

Further details: 30 litres closed (pressure-tight) and open (unpressurised), for supplying one or more taps, can be used as single-circuit, dual-circuit or boiler version. Highly effective rigid foam thermal insulation ensures low standby energy consumption. The specially enamelled inner tank with external current anode offers optimum corrosion protection and a long service life. Stainless steel radiator and heating flange. Can also be used in aggressive water. Power-saving cover with quick-heat button. Single and group or flat supply.
