Comelit Dimmer module

Comelit Group Dimmer Module 20046851

Manufacturer: Comelit Group
Designation: Dimmer Module
Output: 1, 300W
Type: 20046851
Bus System KNX: No
Bus System KNX Wireless: No
Bus System Wireless Bus: No
Bus System LON: No
Bus System Powernet: No
Other Bus Systems: Other
Bidirectional Wireless: No
Mounting Type: DIN Rail
Width in Units: 2
With Bus Coupling: Yes
Expansion Unit Input: No
On-Site/Manual Operation: No
With LED Display: Yes
1-10 V Interface: No
Max. Switching Current (ohmic load): 1.2 A
Max. Switching Current (resistive load): 1.2 A
Max. Switching Power: 300 W
Max. Switching Capacity: 300 W
Number of Outputs: 1
Max. Control Current: 25 mA
Control Current: 25 mA
Protection Class (IP): IP30

Additional Details:
SimpleHome dimmer module for adjusting halogen and compact fluorescent lamps (CFL), dimmable LEDs, and electronic transformers. Output 300W. 1 input for connecting a control button. Dimmer function controlled via a single or double button, motion sensor function with energy-saving mode that allows the lighting to be dimmed when no motion is detected. DIN rail mounting (2 modules). Dimensions: 35x90x58 mm. Maximum BUS consumption: 25 mA.
