Best selling Mobile power distributors
Here's a ranking of the best products in this category. To give you a quick overview, we've also added some key information about the products.
1. Eaton Nockenschalter
The main switch 207145 - T0-1-8200/I1/SVB from Eaton is available as a 1-pole complete device in an enclosure. With a degree of protection of IP65, the lockable main switch 207145 - T0-1-8200/I1/SVB with E-STOP/EMERGENCY STOP function is perfect for various applications. The maximum operating voltage is 690 V AC, the rated continuous current is 20 A and the rated operating power is max. 6.5 kW. For example, the main switch 207145 - T0-1-8200/I1/SVB can be used as a maintenance, repair and safety switch, ON/OFF switch, main switch, control switch, panic switch and manual/automatic switch. Typical areas of application for switch-disconnectors are industrial plants, building technology and trade.
2. MeanWell DIN rail power supply 24 V/DC 4.2 A 100.8 W 1 x
Mean Well has expanded its HDR series of DIN rail power supplies with the HDR-100 model, which offers a power output of 100W. These power supplies are particularly used in building automation and home control, as they all comply with protection class II. The HDR family from Mean Well features a stepped plastic housing, has an input voltage range of 85 to 264VAC (with 277VAC also available), and offers models with 5V, 12V, 15V, 24V, and 48V outputs. Thanks to their slim design, all power supplies have a height of just 90mm and a width of 4SU (70mm). They can be mounted on standard DIN rails TS-35/7.5 and TS-35/15. Additional features include a low no-load consumption of less than 0.3W, a high efficiency of up to 91%, an adjustable DC output voltage, and a wide operating temperature range (-30 to +70 °C). An LED indicator for operation is also included. The HDR series from Mean Well meets the European standard EN61000-3-2 Class A as well as all safety regulations according to UL60950-1, UL508, and EN61558-2-16. Thus, these power supplies are also suitable for use in industrial control and electromechanical devices.
3. Hager Main switch gray 3 pole 63 A
The Hager main switch SH363N is a reliable 3-pole compact switch with a rated current of 63 Amperes. It is designed for use in system power supplies and meets the requirements of DIN EN 60669-1 as well as VDE standards. The switch is housed in a compact casing that offers both functionality and safety. With touch protection according to DIN VDE 0106-100, it ensures safe handling. The Hager SH363N is designed for an input voltage of 400 Volts AC and is suitable for frequencies of 50 to 60 Hz. The screw connection allows for easy and secure installation, while the IP20 protection rating ensures use in dry indoor environments. This main switch is an ideal choice for applications that require a reliable and safe power supply.
- Touch protection according to DIN VDE 0106-100
- Input voltage of 400 V AC
- Suitable for frequencies of 50/60 Hz
- Screw connection for flexible and rigid conductors
- Compact design with IP20 protection rating.
4. Eaton Reversible star-delta-switch 20A 3pin
The Eaton reversing star-delta switch is a highly advanced control device designed for the efficient control of electric motors in industrial applications. With a rated current of 32 amperes and an IP65 protection rating, this switch offers reliable performance and protection against dust and water. The switch features a positive switching action and allows for easy operation through the integrated knob. Its design is suitable for installation, enabling flexible deployment in various environments. The switch complies with IEC/EN 60947 and VDE 0660 standards, underscoring its safety and reliability. With a rated operational power of up to 15 kW, this switch is ideal for applications requiring high performance. The clear labeling on the front panel facilitates operation and identification of the switching positions.
- Switching angle of 60° for precise control
- Positive switching action with a neutral position
- IP65 protection rating for high environmental resistance
- Complies with international standards such as IEC/EN 60947 and VDE 0660
- Suitable for installation in various industrial applications.
5. Phoenix Contact DIN Rail PSU UNO-PS/1AC/48DC/60W
AC or DC input voltage: AC
AC or DC output voltage: DC
Input voltage minimum: 85V AC
Input voltage maximum: 264V AC
Output voltage minimum: 48V DC
Output voltage maximum: 48V DC
Output current: 1.25A
Rated power: 60W
Number of outputs: 1
Electrical phases: 1
Type: Switch mode
Dimensions: 35 x 84 x 90mm
Width: 84mm
Operating time: 1,138,000 hours
UNO single-phase power supplies are the ideal solution for loads up to 240W, especially in compact control boxes, thanks to their high power density and slim dimensions. Save energy through low losses in load-free operation and high efficiency. Slimline housing available in 22.5 mm, 35 mm, and 55 mm designs with a housing depth of only 84 mm. Temperature range: -25 to +70 °C.
Mobile power distributors
−43%
only 1 piece on sale
CHF32.80 was CHF57.90
Phoenix Contact DIN Rail PSU UNO-PS/1AC/48DC/60W
6. Phoenix Contact Hutschienen-Netzteil
The Uno Power power supply impresses in worldwide use with its maximum energy efficiency. Low no-load losses and high efficiency save energy. Due to its high power density, the Uno Power power supply is the perfect solution, especially in compact switch boxes.
Mobile power distributors
−15%
only 15 of 15 remaining on sale
CHF25.– was CHF29.30
Phoenix Contact Hutschienen-Netzteil
7. Eltako FSNT14-12V/12W Switching power supply 12V/12W
Switching power supply with a rated power of 12 W. Standby loss is only 0.2 watts. It is a modular device for mounting on a DIN rail according to EN 60715 TH35. One module is 18 mm wide and 58 mm deep. If the total power requirement of a series 14 bus system exceeds 8 W, additional FSNT14-12V/12W power supplies are required. Each of these supplies a group of actuators that are separated by a terminal bridge on the FSNT14. Included in the delivery are a terminal bridge TB14 1 TE, a jumper 1.5 TE, and a spacer DS14. When loading more than 50% of the rated power, and always with adjacent power supplies and dimmers, a ventilation gap of 1/2 module is required using the spacer DS14. Therefore, this and a long jumper are included in the delivery. The input voltage is 230 V (-20% to +10%). The efficiency is 83%. The stabilized output voltage has a tolerance of ±1% and low residual ripple. The switching power supply is short-circuit proof and features overload and over-temperature protection by switching off with automatic reconnection after the fault is cleared (auto-recovery function). This switching power supply can also be used to create redundancy. For this purpose, only one FSNT14 may be connected in parallel to the integrated power supplies in the FAM14 and FTS14KS and connected with a normal jumper. The FSNT14 should be placed as close as possible to the last actuator in the bus for optimal load distribution.
8. Eltako Switching power supply 24V DC/24W SNT14-24V/24W
The Eltako SNT14-24V/24W is a switching power supply that provides a reliable DC power supply with a nominal voltage of 24V and a nominal power of 24W. It is designed for indoor use and is ideal for applications that require a stable and efficient power supply. With an efficiency of up to 91%, this power supply ensures high energy efficiency and minimizes standby loss to just 0.1 watts. The device is designed as a DIN rail power supply and can be easily integrated into existing systems. It offers a stabilized output voltage with low ripple and is equipped with protection features against short circuit, overload, and overtemperature, allowing for automatic recovery after fault clearance. Its compact design and easy installation make it a practical choice for various applications in electrical engineering.
- Wide input voltage range of 88-264V AC
- Stabilized output voltage with ±1% accuracy
- Automatic recovery after overload or short circuit
- Suitable for mounting on DIN rail EN 60715 TH35
- Low ripple for reliable performance.
9. Brennenstuhl Super-Solid socket block for outdoor use, CH plug-in system IP55, 5x T13 sockets, T13 plug
The Super-Solid power strip from Brennenstuhl is a robust system power supply specifically designed for outdoor use. With a shock- and break-resistant plastic housing, this product not only offers high durability but also provides a wide base for easy handling. The power strip is equipped with five T13 sockets that support a nominal voltage of 230 volts and a nominal current of 10 amperes. The IP55 protection rating ensures that the power strip is protected against splashes and dust, making it ideal for outdoor use. A illuminated 2-pole switch with a protective cover adds extra safety and user-friendliness. The sturdy bracket allows for flexible mounting, so the power strip can be securely attached or hung. With a 3-meter long cable, this power strip is versatile and provides reliable power supply for various outdoor applications.
- Shock- and break-resistant plastic housing for high durability
- Illuminated 2-pole switch with splash protection
- Five T13 sockets with IP55 protection rating for safe outdoor use
- Sturdy bracket for flexible mounting and attachment.
Mobile power distributors
CHF37.90
Brennenstuhl Super-Solid socket block for outdoor use, CH plug-in system IP55, 5x T13 sockets, T13 plug
Type 13
10. PULS DIMENSION DIN rail power supply 20 A 480 W
The DIMENSION DIN rail power supply from PULS is a reliable system power supply specifically designed for mounting on DIN rails. With a nominal power of 480 watts and a nominal current of 20 amperes, this power supply offers stable and efficient power for various applications in automation technology. Its compact design allows for easy integration into existing systems, while its robust construction ensures a long service life. The power supply is suitable for use in industrial environments and guarantees high operational reliability. The output voltage of 28 volts is ideal for many industrial applications, and the input voltage of 240 volts provides broad compatibility. This product is an excellent choice for anyone in need of a powerful and reliable power supply.
- Robust construction for industrial applications
- Easy mounting on DIN rails
- High operational reliability and efficiency.
