Vortice 300/12
Delivered between Wed, 12.8. and Thu, 13.8.
Only 3 pieces in stock at third-party supplier
Only 3 pieces in stock at third-party supplier
Supplied by
Creoven CH
free shipping
Max. Air flow rate2
Product details
Dimensions and technical details:
- Voltage: 220-240 V ~ 50 Hz
- Colour: White
- Material: Impact-resistant, UV-resistant ABS plastic
- Nominal size: 300 mm
- Speed levels: 1
- Wattage: 45 W
- Current consumption: 0.21 A
- Revolutions per minute supply air: 1150
- Revolutions per minute exhaust air: 850
- Maximum airflow rate supply air: 850 m³/h
- Maximum airflow rate exhaust air: 1200 m³/h
- Sound pressure level Lp-3m: 40.7 dB(A)
- IP rating: IPX4
- Protection class: II
- Maximum ambient temperature: +50°C
- Weight: 7.2 kg
- Plain bearing
- Automated internal shutter flap prevents cold air from coming in once the fan is turned off (can be opened manually)
- Optional CR controllers allow reversing and speed control
Model:
- A: 495 mm
- C: 10.5 mm
- D: 11.5 mm
- E: 210 mm
- Ø Cutout: 435-440 mm.
Max. Air flow rate | 1200 m³/h |
Suitable for pipe diameter | 300 mm |
Power consumption | 45 W |
Item number | 17446585 |
Manufacturer | Vortice |
Category | Ventilation fan |
Manufacturer No. | 12413 |
Release date | 9.11.2021 |
Colour | White |
Exact colour description | White |
Material group | Plastic |
Material | Plastic |
Max. Air flow rate | 1200 m³/h |
Noise emission | 41 dB |
Suitable for pipe diameter | 300 mm |
Power supply | Electrical connection |
Mains voltage | 220 - 240 V |
Power consumption | 45 W |
Country of origin | Germany, Italy |
CO₂ emissions | 22.46 kg |
Climate contribution | CHF 0.54 |
Length | 23.20 cm |
Width | 49.50 cm |
Height | 49.50 cm |
Weight | 7200 g |
