Vortice 300/12

Dimensions and technical details:

• Voltage: 220-240 V ~ 50 Hz
• Colour: White
• Material: Impact-resistant, UV-resistant ABS plastic
• Nominal size: 300 mm
• Speed levels: 1
• Wattage: 75 W
• Current consumption: 0.41 A
• Revolutions per minute (supply air): 1310
• Revolutions per minute (exhaust air): 1230
• Maximum airflow rate (supply air): 1000 m³/h
• Maximum airflow rate (exhaust air): 1750 m³/h
• Sound pressure level (Lp-3m): 53.5 dB(A)
• IP rating: IPX4
• Protection class: II
• Maximum ambient temperature: +50°C
• Weight: 7.2 kg
• Ball-bearing
• Automated internal shutter flap prevents cold air from coming in once the fan is turned off (can be opened manually)
• Optional CR controllers allow reversing and speed control

Model:

• A: 495 mm
• C: 10.5 mm
• D: 11.5 mm
• E: 210 mm
• Ø Cutout: 435-440 mm.
