TE Sensors Non-locking actuator switch,2NO+1NC

Ratings
BrandMore from TE Sensors
Delivered between Wed, 27.5. and Thu, 11.6.
More than 10 pieces in stock at supplier
free shipping

Product details

Connection type: Screw fastening
Interlock type: Actuator
Contact configuration: 1 NC contact / 2 NO contacts
Housing material: Zamak
AC voltage max: 240V
DC voltage max: 250V
Safety contacts: 1 NC contact / 2 NO contacts
Range: Preventa
Number of head positions: 8
Series: XCSA
Width: 40mm

Complies with EN1088, EN60204 standards. Actuating elements must be ordered separately. XCSA safety interlock switch features three positive opening contacts as standard when the guard is opened. A key-operated lock allows the guard to be positively locked. Optional version with orange LED to indicate guard open/closed. Robust metal design according to DIN. Rotary heads can be rotated 360° in 90-degree steps. Eight inputs for actuating elements and one threaded input. Minimum actuating force for positive opening: 20 N. Protection class IP67. Improved productivity due to the third contact reserved for diagnostics. Preventa XCS safety interlock switch.

Key specifications

Nominal current
10 A
Number of outlets
2x
Protection type (IP code)
IP67

General information

Item number
9942061
Manufacturer
TE Sensors
Category
Mobile power distributors
Manufacturer No.
XCSA502
Release date
22.10.2018
External links
Manufacturer's site (de)

Material

Material group
Metal
Material
Metal

Mobile power distributor features

Nominal current
10 A
Number of outlets
2x
Area of use
Inside
Contact Configuration
1 break contact, 2 normally open contacts
Protection type (IP code)
IP67

Origin

Country of origin
France

Voluntary climate contribution

CO₂ emissions
15.15 kg
Climate contribution
CHF 0.36

Scope of delivery

Items per sales unit
1 pcs.

Product dimensions

Height
114 mm
