TE Sensors Metal limit switch w/metal end plunger

Ratings
Delivered between Wed, 22.10. and Sat, 8.11.
Free shipping starting at 50.–

Product details

Actuator type: Plunger
Contact number and position: 2-pole
Contact configuration: Normally open/normally closed contact
Current max: 3 A
Body material: Zinc alloy
AC voltage max: 240 V
DC voltage max: 250 V
Series: OsiSense XC
Contact type: Snap action
Connection type: Screw mounting
Length: 65 mm
Width: 31 mm
Mechanical life min: 150,000 cycles

Compact type. User-friendly Schneider Electric Osiconcept compact electromechanical limit switches. These limit switches are made of reinforced UL-VO thermoplastic and offer double insulation and protection to IP66. Features and benefits include visible operation, precise operating points, double insulation, 1 NO and 1 NC contact, and M16 x 1.5 cable entry. Rated for 240 V AC, 3 A.

Key specifications

Nominal current
3 A
Number of outlets
1 x
Protection type (IP code)
IP66, IP67
Item number
9944083

General information

Manufacturer
TE Sensors
Category
Mobile power distributors
Manufacturer no.
XCKD2110P16
Release date
22.10.2018

Material

Material group
Metal
Material
Metal

Mobile power distributor features

Nominal current
3 A
Number of outlets
1 x
Area of use
Inside
Contact Configuration
Normally open/ normally closed
Actuator Type
Dome tappet
Protection type (IP code)
IP66, IP67

Origin

Country of origin
Indonesia

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Items per sales unit
1 pcs.

Product dimensions

Width
31 mm
Length
30 mm
Height
65 mm
