Siemens Soft starter 3RW3046-1BB14 (3RW30461BB14)

SIRIUS Soft Starter S3 80 A, 45 kW/400 V, 40 °C AC 200-480 V, AC/DC 110-230 V screw terminals. The SIRIUS 3RW30 soft starter is designed for standard applications for the gentle starting of three-phase asynchronous motors. It allows for stepless starting, reduces current peaks, avoids voltage fluctuations in the power supply during start-up, relieves the power supply network, and decreases mechanical stress on the drive. Additionally, it offers significant space and wiring savings compared to star-delta starters and frequency converters. The soft starter is maintenance-free and easy to handle. The integrated bypass ensures a compact design and lower heating in the control cabinet. There are worldwide approvals, such as IEC and UL/CSA. The 3RW soft starters are available for networks up to 690 V and offer a wide power range with different control supply voltages as well as screw and spring clamp connections. For models 3RW30/40, additional variants with 24 V control supply voltage are available. Some of the 3RW40 up to size S3, as well as all 3RW44, also offer thermistor motor protection. With the optional connection module, the soft starters can be mounted on circuit breakers, including variants with spring clamp connections. Simple, efficient, always up to date - the SIRIUS system modular concept.
