Siemens RCD type 63A Npol. 00mA 400V 4TE

Ratings
Delivered between Fri, 6.6. and Tue, 17.6.

Product details

Siemens Digital Industry RCD 5SV3446-6

Manufacturer: Siemens Digital Industry
Designation: Type A RCD, 100 mA, 63 A
Type: 5SV3446-6
Number of Poles: 4
Rated Voltage: 400 V
Rated Current: 63 A
Rated Residual Current: 0.1 A
Mounting Type: DIN Rail
Residual Current Type: A
Selective Type: No
Delayed Type: No
Short-Circuit Strength (Icw): 10 kA
Surge Current Strength: 1 kA
Voltage Type: AC
With Locking Device: Yes
Frequency: 50 Hz
Additional Devices Possible: Yes
Protection Class (IP): IP20
Width in Modular Units: 4
Installation Depth: 70 mm
Ambient Temperature During Operation: -25 to 45 °C
Connectable Conductor Cross-Section Multi-Wire: 0.75 to 35 mm²
Connectable Conductor Cross-Section Single-Wire: 0.75 to 35 mm²
Explosion-Proof: No

The SENTRON 5SV3 RCD provides comprehensive protection for people and property against electric shock. The RCDs ensure reliable safety during installation through the standard included gripping and touch protection. With the convenient slider manual operation, you can easily detach the RCDs from the DIN rail or busbar system without tools. The data matrix code on the device provides quick access to all technical data in the Siemens Industry Online Support App. The SENTRON protective devices can be expanded with a wide range of functions using the continuous accessories from the system modular kit. Optimal technology for your safety - only from Siemens.

EAN: 4001869427829.

Key specifications

Circuit breaker type
Fault current circuit breaker
Length
70 mm
Width
72 mm
mounting style
Top-hat rail
number of poles
4
Item number
13052024

General information

Manufacturer
Siemens
Category
Residual-current device
Manufacturer no.
5SV3446-6
Release date
7.4.2020
External links
Manufacturer's site (de)

Circuit Breaker Features

Circuit breaker type
Fault current circuit breaker
mounting style
Top-hat rail
number of poles
4
Tripping characteristic
A
Rated current
63 A
Rated current
0.1 A
Rated voltage
400 V
voltage type
AC
Residual current (rated differential current)
0.10 A
Protection type (IP code)
IP20

Origin

Country of origin
Germany

Sustainability

Manufacturer commitment
RE100, SBTi

Voluntary climate contribution

Manufacturer compensation
According to RE100, the manufacturer Siemens fully compensates for its energy consumption, leading to a reduction in emissions.
CO₂-Emission
Climate contribution

Scope of delivery

Items per sales unit
1 Piece

Product dimensions

Length
70 mm
Width
72 mm
Height
90 mm
Weight
372 g

Package dimensions

Length
9.50 cm
Width
8.40 cm
Height
7.90 cm
Weight
341 g
