Siemens RCD short time delayed 8A 3ma

Siemens Dig.Industr. RCD 5SV3647-4KK14

Manufacturer: Siemens Dig.Industr.
Description: RCD Type B+, 300 mA, 80 A
Type: 5SV3647-4KK14
Number of Poles: 4
Rated Voltage: 400 V
Rated Current: 80 A
Rated Residual Current: 0.3 A
Mounting Type: DIN Rail
Residual Current Type: B+
Selective Type: No
Short-Time Delayed Type: Yes
Short-Circuit Strength (Icw): 10 kA
Surge Current Strength: 3 kA
Voltage Type: AC
With Locking Device: Yes
Frequency: 50 Hz
Additional Devices Possible: Yes
Protection Class (IP): IP20
Width in Modular Units: 4
Installation Depth: 70 mm
Ambient Temperature During Operation: -25..45 °C
Connectable Conductor Cross-Section Multi-Wire: 0.75..35 mm²
Connectable Conductor Cross-Section Single-Wire: 0.75..35 mm²
Explosion-Proof: No

Further Details: RCD, 4-pole, Type B+, short-time delayed, In: 80 A, 300 mA, Un AC: 400 V.

The SENTRON 5SV3 RCDs provide comprehensive protection for people and property against electric shock. They ensure reliable safety during installation with the standard included gripping and touch protection. With the convenient sliding manual operation, you can easily detach the RCDs from the DIN rail or busbar assembly without tools. The datamatrix code on the device gives you quick access to all technical data in the Siemens Industry Online Support App.

The SENTRON protective devices can be expanded with a wide range of functions using the consistent accessories from the system modular kit. Optimal technology for your safety - only from Siemens.

EAN: 4001869549217.
