Siemens Motor starter reversing starter 500V

Series: 3RM1
Module type: Reversing starter
Range: Sirius
Power: 0.75 kW
Control voltage: 24 V DC
Current range: 0.4 to 2.0 A
Size: 22.5 x 141.6 x 100 mm

IEC/EN 60947-4-2, IEC 61508-1: SIL 3, ISO 13849: PLe, CCC, CSA, UL, EAC, ATEX. The reversing motor starter Sirius 3RM1 is a compact device with a width of 22.5 mm that combines various functions in a single housing. It consists of a combination of relay contacts, power semiconductors (in hybrid technology), and an electronic overload relay for switching induction under normal operating conditions.

Properties and advantages:

• Reversing starter
• Overload protection
• Fast diagnostics with LED test button/reset button
• Energy-saving
• Reduced wiring
• Easy connection
• Small width: 22.5 mm

Type of electrical connection:
Screw terminals for main and control circuits.
Spring terminals (pluggable) for main and control circuits.
Screw terminals for main circuit, spring terminals (pluggable) for control circuit.
