Siemens 1 pole miniature circuit breaker

Siemens digital industrial circuit breaker 5SL6113-7

Manufacturer: Siemens Digital Industrial
Description: Circuit breaker C13A 1-pole 6kA
Type: 5SL6113-7
Mounting depth: 70 mm
Tripping characteristic: C
Total number of poles: 1
Number of protected poles: 1
Rated current: 13 A
Rated voltage: 400 V
Rated short-circuit capacity Icn according to EN 60898 at 230 V: 6 kA
Type of voltage: AC
Rated short-circuit capacity Icn according to EN 60898 at 400 V: 6 kA
Rated short-circuit capacity Icu according to IEC 60947-2 at 230 V: 6 kA
Rated short-circuit capacity Icu according to IEC 60947-2 at 400 V: 6 kA
Frequency: 50 Hz
Energy limitation class: 3
Flush mounting: no
Switching neutral conductor: no
Overvoltage category: 3
Degree of pollution: 2
Additional devices possible: yes
Width in division units: 1
Protection class (IP): IP20
Ambient temperature during operation: -25 to 45 °C
Connectable conductor cross-section multi-stranded: 0.75 to 25 mm²
Connectable conductor cross-section single-stranded: 0.75 to 25 mm²
Explosion-proof: no

Siemens digital industrial circuit breaker 5SL6113-7: Additional details
Circuit breaker 230/400V 6kA, 1-pole, C, 13A
SENTRON 5SL circuit breakers provide safe short-circuit and overload protection for standard applications in residential and commercial buildings. Tool-free installation and removal of the device. Easy wiring of the supply through the rear busbar. The 5SL circuit breakers are available in 1-, 2-, 3-, 4-, as well as 1+N and 3+N pole configurations, along with various special types. A wide range of accessories, such as auxiliary switches, allows for versatile function expansion. Simply safe with SENTRON protection devices.
