The Shelly 2PM Gen4 is an advanced dual-channel dimming actuator that enables precise power monitoring. It supports various communication protocols, including WiFi, Bluetooth and Zigbee, and is designed for installation behind switches, sockets or lamp outlets. This device enables easy control and automation of lighting, fans, shutters and other bi-directional AC motors. With its compact design, the dimming actuator can be easily installed in wall and ceiling boxes, making it a flexible solution for modern smart home applications. Matter-certified for seamless integration into smart home systems. Multi-protocol chip for simultaneous communication via WiFi and Zigbee. Bluetooth functionality for direct communication with battery-powered devices. Local operation of all main functions, even in the event of network problems. High compatibility with over 200 partner systems, including Google Home and Amazon Alexa.
Actuator type | Switch actuator |
communicating | Wireless |
Items per sales unit | 1 x |
Smart Home Systems | Amazon Alexa |
Smart Home Protocol | Matter, ZigBee |
Mounting type | Flush-mounted |
Item number | 56591716 |
Manufacturer | Shelly |
Category | Actuator |
Manufacturer no. | SHELLY_2PM_GEN4 |
Release date | 21.3.2025 |
Sales rank in Category Actuator | 1 of 1465 |
Colour | Black |
Exact colour description | Black |
Material group | Plastic |
Material | Plastic case |
Actuator type | Switch actuator |
Max. Switching capacity | 2300 W |
rated current | 10 A |
Operating voltage | 240 V |
Number of switching outputs | 2 x |
Mounting type | Flush-mounted |
Smart Home | Compatible |
Smart Home Systems | Amazon Alexa |
Smart Home Protocol | Matter, ZigBee |
communicating | Wireless |
Radio frequency | 2400000000 Hz |
Requires Smart Home Hub | No |
Country of origin | China |
CO₂-Emission | |
Climate contribution |
Items per sales unit | 1 x |
Length | 42 mm |
Width | 16 mm |
Height | 38 mm |
Weight | 30 g |
Length | 8 cm |
Width | 5.20 cm |
Height | 4.50 cm |
Weight | 80 g |
