Schneider Electric C103100S Switch-disconnector ComPacT NSX100NA 3 poles

Schneider Electric Load Break Switch ComPacT C103100S

Manufacturer: Schneider Electric
Designation: Load Break Switch ComPacT NSX100NA, 3 poles
Type: C103100S
Design as Main Switch: yes
Design as Maintenance/Repair Switch: yes
Design as Safety Switch: no
Design as Emergency Stop Device: no
Design as Reversing Switch: no
Number of Switches: 1
Max. Rated Operating Voltage Ue for AC: 690 V
Rated Operating Voltage: 690 V
Rated Continuous Current Iu: 100 A
Rated Continuous Current for AC-23, 400 V: 100 A
Rated Continuous Current for AC-21, 400 V: 100 A
Rated Short-Time Current Strength Icw: 1.8 kA
Number of Poles: 3
Number of Auxiliary Contacts as Changeover: 5
Motor Drive Optional: yes
Motor Drive Integrated: no
Voltage Release Optional: yes
Device Design: Built-in Device Fixed Installation Technology
Suitable for Floor Mounting: yes
Suitable for Front Mounting 4-Hole: yes
Suitable for Central Front Mounting: no
Suitable for Panel Installation: yes
Suitable for Intermediate Installation: no
Color of Actuating Element: black
Design of Actuating Element: Knob
Lockable: yes
Connection Type Main Circuit: Screw Connection
Protection Class (IP), front side: IP30

This ComPacT NSX100NA is a complete 3-pole load break switch. It is used for controlling and isolating power distribution circuits and requires upstream protection. The operating current is 100 A at 415 VAC 50/60 Hz for usage categories AC22A and AC23A. The operating voltage is 690 VAC 50/60 Hz. It is equipped with a range of optional functions and accessories that can be used with the ComPacT NSX circuit breakers. The dimensions for this 3-pole version are 105 mm x 161 mm x 86 mm. It complies with international standards (IEC 60947), CCC, EAC, and marine specifications.
