RS PRO SY 8 core 1.0mm control cable 50m

Number of conductors: 8
Cross-section of the conductor: 1 mm²
Outer diameter: 12.5 mm
Rated current: 15 A
Operating temperature min: -40 °C
Operating temperature max: +80 °C
Operating voltage: 300/500 V
Strands: 32/0.20 mm
Sheath material: Polyvinyl chloride (PVC)
Sheath color: Transparent
Protective conductor: Yes
Shielding type: Braid

This cable complies with ECD 73/23/EEC (Low Voltage Directive). SY control cables are numerically coded control and connection cables for flexible and fixed installations with medium mechanical stress. The SY cable can be used in dry, damp, and wet environments. UV protection is also included when installed outdoors and within the temperature range. These cables are generally resistant to acids, corrosive solutions, and certain oils at room temperature. The SY cable can also be used for supplying and connecting machine tool controls, control devices for conveyor belts, production lines, as well as measuring, control, and computer units. These cables are ideal for free movements without tensile stress or forced movements. The galvanized steel wire braid enhances mechanical protection. Features and benefits.
