Phoenix Contact Overvoltage protection plug 10
Protection level
Product details
The surge protection plug from Phoenix Contact is a reliable surge arrester specifically designed for 2-wire, ungrounded signal circuits. With a rated voltage of 110 V AC, this plug provides effective protection against surges caused by lightning strikes or other electrical disturbances. The LSA-PLUS plug (COMTRAB CTM) is made from high-quality polyamide and features a compact design that allows for easy integration into existing systems. With a lightning impulse current of up to 5 kA and a protection level of 260 V, this surge protection device ensures high safety for your electrical installations. The IP20 protection class makes it ideal for indoor use, while the operating temperature range of -25 °C to 75 °C allows for versatile applications.
- Lightning impulse current of 5 kA for high protection
- Rated voltage of 110 V AC
- Protection level of 260 V
- Made from durable polyamide
- IP20 protection class for indoor use.
Surge protection type | Surge arrester |
Number of conductors | 2 x |
Item number | 8416835 |
Manufacturer | Phoenix Contact |
Category | Surge protection |
Manufacturer no. | 2838526 |
Release date | 20.4.2018 |
Colour | Black |
Exact colour description | Black |
Material group | Plastic |
Material | Polyamide |
Surge protection type | Surge arrester |
Number of conductors | 2 x |
Lightning impulse current | 5 kA |
Rated leakage surge current | 0 kA |
Nominal voltage | 110 V |
Protection level | 260 V |
Protection type (IP code) | IP20 |
Country of origin | Germany |
CO₂-Emission | |
Climate contribution |
Length | 0.05 m |
Width | 0 m |
Height | 0.02 m |
Weight | 10.30 g |
