JUNG SCHUKO socket outlet

Jung SCHUKO socket outlet 16A 250V CD 1520 NBFNA O Manufacturer :Jung Designation :SCHUKO socket outlet 16A 250V with labelling field Type :CD 1520 NBFNA O Version :SCHUKO Earth contact :yes Earth contact round :no Number of active contacts (round) :2 With signal lamp :no With built-in USB power supply :no Number of units :1 Number of phases :1 Imprint/labelling :without Connection type :Plug-in terminal With hinged cover :no With increased touch protection :no Text field/inscription area :yes Colour :orange RAL number (similar) :2004 Metallic colour :no Transparent :no Lockable :no Ejector mechanism :no Insulated installation :no With functional lighting :no With orientation light :no Overvoltage protection :no Residual current protection :no With microfuse :no Special power supply :Additional safety supply (orange) Mounting type :Flush-mounted Mounting type :Fastening with screw Material :Plastic Material grade :Thermoplastic Halogen-free :yes Surface protection :other Finish :glossy Antibacterial treatment :no With on/off switch :no With loop-through function :no Twisted central insert :no Rated current :16 A Rated voltage :250 V Suitable for protection class (IP) :IP20 Device width :67 mm Device height :67 mm Device depth :0 mm Compatible with Apple HomeKit :no Compatible with Google Assistant :no Compatible with Amazon Alexa :no IFTTT support available :no Cover :Central plate For "difficult conditions" (according to VDE) :no Jung SCHUKO socket outlet 16A 250V CD 1520 NBFNA O: further details protective contact® socket outlet, orange (for ZSV) with labelling field 6 x 37 mm with spring terminals for rigid and untreated flexible conductors up to 2.5mm2 Connection terminals according to DIN VDE 0620 (screw fixing, without fixing claws) Support ring is integrated into the protective measure via an earthing bar. Material: thermoplastic Dimensions (W x H): 67 x 67 mm , EAN: 4011377076617.
