Hüppe SolvaPro pivot door with side panel in recess, right-fixing, width: 120cm, height:200cm

Hüppe SolvaPro 1x partially framed square swing door with side panel for niche installation

Product features:

• Swing door with side panel
• Right-hand mounting
• Designed for installation in a niche
• Partially framed door with a glass wing that opens inward and outward, with a side panel
• Glazing made of 8 mm single-pane safety glass, optionally with the easy-care surface finish HÜPPE Anti-Plaque
• Profiles made of high-quality anodized aluminum, handle made of high-quality metal
• Adjustable wall profile by 15 mm
• Tube hinge with infinitely adjustable lift-lower mechanism and 5 mm lift effect
• With splash guard strip (height 10 mm) for optimal sealing, or can be installed without a threshold
• Continuous magnetic strips and sealing profiles, as well as a water-repellent horizontal sealing strip
• HÜPPE bead system - installation without visible screws in the wall strip area
• With stabilizer (inside)
• Installation possible on shower tray or tiled floor

Dimensions:

• Bathtub installation size: 118.5 – 121.5 cm
• Installation size center glass: 118.5 – 121.5 cm
• Width of side panel: 43.2 – 44.7 cm
• Width of entrance: 68 cm
• Height: 200 cm

Colors/Finishes:

• Custom RAL colors available upon request as profile color
• Additional glass/decor options available upon request (gray, bronze, mirror glass, sandblasted decor Liquid, sandblasted decor Nature)
• Angled cutouts possible (upon request, additional charge per angle)
• Custom handles selectable from the HÜPPE range upon request, handle only available in color 092 high-gloss silver

Assembly condition:

• Partially assembled

Included in delivery:

• Mounting materials, installation instructions

Attention:

• Privatima and SandPlus can only be offered up to a width of 1600 mm for production technical reasons
• The specified dimensions of the shower cabin refer only to installation on shower trays. For floor-level installation, the dimensions may vary; please provide the exact dimensions of the shower area before ordering!.
