Hüppe HÃPPE Xtensa pure Walk-In sliding door 1-piece, with fixed segment, width:120cm, right stop, crossb

Hüppe Xtensa pure 1 x Walk-In Sliding Door

Product features:

• For installation on shower trays and tiled floors
• Free-standing, for installation in a niche or in combination with a side panel
• Partially framed Walk-In with a sliding door segment that opens to one side
• A partially framed fixed segment
• Glazing: 6 mm (fixed segment) and 8 mm (door) single-pane safety glass
• Optional with easy-care surface finish HÜPPE Anti-Plaque
• 90° crossbar
• Slim wall profile made of aluminum
• Adjustment option in the wall profile: 12 mm, plus up to 200 mm via overlapping glass elements
• Easy cleaning due to the flush interior roller system
• Rollers are flush-mounted and height-adjustable
• Floor profile (height 10 mm)
• Continuous magnetic strips and sealing profiles
• Right-side mounting

Dimensions:

• Adjustment range standard: 3.2 cm
• Bathtub installation measurement standard: 108.8 cm to 120 cm
• Bathtub installation measurement in niche: 110.5 cm to 121.7 cm
• Bathtub installation measurement with side panel: 112.4 cm to 123.6 cm
• Entry width in niche: 42.2 cm to 52.1 cm
• Entry width with side panel: 40.3 cm to 50.2 cm
• Height: 200 cm

The specified dimensions of the shower cabin refer only to installation on shower trays. For floor-level installation, the measurements may differ; please provide the exact dimensions of the shower area before ordering! For this item, measurement and installation service is recommended!

Scope of delivery:

• Including mounting materials, cleaning tools, and installation instructions
• Including HÜPPE bead system - installation without visible screws in the area of the wall profile

Installation accessories:

• A niche extension set is required for the installation of the sliding door in a niche. Please order separately!
• Select+ wall profile and ceiling connection available for optional order.
