Eupen EUP H07V-K

Diverse EUP H07V-K 1,5 rt Ri.100 H07V-K 1,5 rt Manufacturer :Diverse Designation :EUP H07V-K 1,5 rt Ri.100 Stranded flexible Type :H07V-K 1,5 rt Conductor material :Copper Conductor cross-section :1,5 mm² AWG size :0 Conductor diameter :1,5 mm Conductor class Kl.5 :finely stranded Number of cores :1 Core insulation material :polyvinyl chloride (PVC) Core identification :colour Core colour :red With protective conductor :no Screen :no Double wire :no Reinforcement/armouring :without Sheathing material :without Reaction to fire class according to EN 13501-6 :Eca Halogen-free acc. to EN 60754-1/2 :no Flame-retardant :acc. to IEC/EN 60332-1-2 Low smoke acc. to EN 61034-2 :no Cold-resistant acc. to EN 60811-504+505+506 :no Oil-resistant acc. to EN 60811-404 :no Outer diameter approx. :2.9 mm Perm. cable outer temperature during assembly/handling :-5..50 °C Perm. cable outer temperature after assembly without shock :-25..70 °C Nominal voltage U0 :450 V Nominal voltage U :750 V Various EUP H07V-K 1,5 rt Ri.100 H07V-K 1,5 rt: more details According to EN 50525-2-31. Installation in electrical conduit on or under plaster or in similar closed systems. Suitable for protected fixed installation, in or on lighting systems or switching and control devices for voltages up to 1 000 V AC or up to 750 V DC to earth. , EAN: 5413260576737.
