Product details
The Eaton P3-63/I4/SVB/N is a highly advanced safety switch designed for system power supply. With a rated current of 63 amperes and a maximum operating voltage of 690 volts, this switch provides a reliable solution for various electrical applications. The switch is designed as a rotary switch and features three poles, making it ideal for use in industrial and commercial environments. A notable feature is the option for floor mounting, which ensures a stable installation. Additionally, the switch is lockable, providing extra safety during maintenance work. The IP65 protection rating ensures that the switch is protected against dust and water, expanding its usability in different environments. Therefore, the Eaton P3-63/I4/SVB/N is a robust and safe choice for anyone in need of a reliable main switch.
- Floor mounting for stable installation
- Lockable design for additional safety
- IP65 protection rating for dust and water resistance
- Suitable for industrial and commercial applications
- Rotary switch with three poles for versatile applications.
Nominal current | 63 A |
Nominal voltage | 690 V |
Number of outlets | 1 x |
Circuit breaker type | Auxiliary switch, Circuit breaker, FI-LS fire protection switch, Miniature circuit-breaker/residual current circuit-breaker combination, Motor protection switch |
Protection type (IP code) | IP65 |
Item number | 16180263 |
Manufacturer | Eaton |
Category | Mobile power distributors |
Manufacturer no. | 207349 |
Release date | 30.6.2021 |
External links |
Colour | Red |
Exact colour description | Red, Yellow |
Nominal current | 63 A |
Nominal voltage | 690 V |
Number of outlets | 1 x |
Area of use | Inside |
Number of poles | 3 x |
Contact Configuration | 1 x 1 normally open or normally closed contact |
Actuator Type | Rotary drive |
Power | 30 kW |
input voltage | 690 V |
number of poles | 3 |
Protection type (IP code) | IP65 |
Circuit breaker type | Auxiliary switch, Circuit breaker, FI-LS fire protection switch, Miniature circuit-breaker/residual current circuit-breaker combination, Motor protection switch |
Country of origin | Germany |
Manufacturer commitment | SBTi |
CO₂-Emission | |
Climate contribution |
Items per sales unit | 1 pcs. |
Scope of delivery | Auxiliary switch contact can be retrofitted |
Width | 160 mm |
Length | 139 mm |
Height | 240 mm |
