The bikes in the i-SPEED series are designed for frequent riders who find 25 km/h insufficient. These S-Pedelecs are approved for speeds of up to 45 km/h. They are equipped with the powerful Yamaha PW-X2 45 motor, providing up to 80 Newton meters of torque. Whether for asphalt or unpaved roads, Wheeler has the right model for everyone, whether for daily commuting or for enthusiasts of extensive tours. The bicycles are equipped with reinforced E-MTB components and 4-piston brakes to handle the increased demands. The excellent features also enhance the riding pleasure.
Number of gears | 11 x |
Braking system | Hydraulic |
Weight | 24 kg |
E-bike type | Electric mountain bike |
Item number | 25305403 |
Manufacturer | Wheeler |
Category | Electric bikes |
Release date | 25.4.2023 |
Sales rank in Category Electric bikes | 8 of 665 |
Colour | Blue |
Exact colour description | Blue |
Target group | Women |
E-bike type | Electric mountain bike |
Max. load | 150 kg |
Number of gears | 11 x |
Model year | 2022 |
Motor position | Mid-engine |
Electric motor brand | Yamaha |
Power | 500 W |
Max. torque | 80 Nm |
Max. range | 120 km |
Pedal assistance | Up to 45 km/h |
Power capacity | 600 Wh |
Capacity | 16.20 Ah |
Voltage | 37 V |
Items per sales unit | 1 x |
Frame size e-bike | 165-179 cm = M |
Frame height | 53 cm |
Frame size | M |
Frame material | Aluminium |
Frame shape | Diamond frame |
Fork model | Fox 34 Float Rhythm 29"/27.5"+ |
Handlebar model | 15mm rise, 31.8 mm, 9°ANGLE, LEVELNINE RACE RISER BAR 780mm |
Seatpost model | 31.6 mm, PROMAX SP-2028TLA, WITH REAR LIGHT MOUNT |
Saddle model | Ergon SM10 E-Mountain |
Bicycle damper model | 27.5"+, FOX 34 FLOAT RHYTHM 29" |
Travel rear shock | 140 mm |
Suspension fork model | Fox 34 Float Rhythm 29"/27.5"+ |
Suspension travel suspension fork | 140 mm |
Gearshift model | CLAMP TYPE, DIRECT ATTACH TO BRAKE LEVER, SHIMANO XT SL-M8130 |
Rear derailleur model | 11-speed, SHIMANO XT RD-M8130 SGS SHADOW PLUS DESIGN |
Drive type | Derailleur gears |
Cassette model | 11-50 THEETH, Shimano CS-LG600, Sram 11 Speed |
Number of pinions | 11 x |
Chain model | SHIMANO CN-LG500 11-SPEED |
Crankset model | 11-speed, SHIMANO XT RD-M8130 SGS SHADOW PLUS DESIGN |
Number of chainrings | 11 x |
Braking system | Hydraulic |
Brake model | 4-PISTON HYDRAULIC DISC BRAKE, MAGURA MT5 eSTOP, R:203mm, ROTORS F:203mm |
Wheel diameter | 29" |
Hub Model | 12x148mm BOOST, 32 HOLES, Boost Thru Axle, SUNRINGLE WHEELSET DUROC 37SD COMP |
Rim model | ALLOY 6061 D.B. |
Taillight model | Supernova |
Country of origin | Taiwan |
CO₂-Emission | |
Climate contribution |
Weight | 24 kg |
Length | 200 cm |
Width | 100 cm |
Height | 80 cm |
Weight | 24 kg |
