Eaton Room controller

Eaton Room Controller Touch CRCA-00/09

Manufacturer: Eaton
Designation: Room Controller Touch anthracite
Type: CRCA-00/09
Bus system KNX: No
Bus system KNX radio: No
Bus system radio bus: Yes
Bus system LON: No
Bus system Powernet: No
Other bus systems: xComfort radio bidirectional: Yes
Composition: Basic element with complete housing
Mounting type: Surface-mounted
With on-site operation: Yes
With theft/dismantling protection: No
With LED display: No
With display: Yes
Material: Plastic
Material quality: Thermoplastic
Surface protection: Painted
Finish: Glossy
Colour: Anthracite
RAL number (similar): 7016
Transparent: No
External sensor: Yes
Manual setpoint adjustment: Yes
Presence push-button: No
Parallel operation possible: Yes
Protection class (IP): IP20
With bus coupling: No
Class of temperature controller: IV
Power consumption in standby mode: 0.05 W
Min. depth of device socket: 0 mm

Eaton Room Controller Touch CRCA-00/09: Further details
The room controller Touch, anthracite, with temperature and humidity sensor is suitable for monitoring and controlling the room climate either individually or together with an intelligent device. It is operated via the touch display with backlighting. The user-programmable weekly programme timer and four operating modes offer maximum flexibility to meet specific needs. Floor temperature control is supported via an optional external wired floor temperature sensor (PT1000). Two optional touch buttons on the display are available for controlling other xComfort functions/actuators. The room controller Touch is compatible with many 55 mm frames from the switch industry. The unit is battery operated and as no switch, junction, or installation box is required, it can be easily mounted anywhere (screwed and glued). Batteries included, but it can also be optionally powered with a mains adapter.
