Banana Pi BPI-M1 - Dual-Core Single Board Computer

Banana Pi is an open-source hardware platform. The Banana Pi model BPI-M1 features a dual-core processor and runs on Android, Debian Linux, Ubuntu Linux, OpenSuse Linux, and other operating systems compatible with the Raspberry Pi B and Cubieboard. The Banana Pi BPI-M1 includes a Gigabit Ethernet port and a SATA socket. It operates smoothly with Android 4.2.2. The board is roughly the size of a credit card. It also supports video games, as it provides 1080p HD video output. The GPIO header is compatible with Raspberry Pi and can directly run Raspberry Pi images.

CPU: A20 ARM Cortex-A7 dual-core
GPU: ARM Mali400MP2, compliant with OpenGL ES 2.0/1.1
Memory (SDRAM): 1 GB DDR3 (shared with GPU)
Internal Storage: SD (max. 64 GB) / MMC card slot, up to 2TB on 2.5 SATA disk
Network Interface: 10/100/1000 Ethernet RJ45, optional Wi-Fi
Video Input: CSI interface allows connection of a camera module
Video Output: HDMI, CVBS, LVDS/RGBA
Audio Output: 3.5 mm jack and HDMI
Power Supply: 5 Volts via MicroUSB (DC input only) and/or MicroUSB (OTG)
USB 2.0 Ports: 2 (directly from Allwinner A20 chip)
Buttons:

• Reset button: next to MicroUSB port
• Power button: next to reset button
• Boot button (optional): behind HDMI port

GPIO (2x 13) Pins: GPIO, UART, I2C bus, SPI bus with two chip selects, CAN bus, ADC, PWM, +3.3 V, +5 V, Ground
LED: Power and RJ45
Remote: IR (optional)
Operating System: Android 4.2, Linux, etc.
Dimensions: 92 x 60 mm
Weight: 48 g
Temperature Range: -15°C to 75°C.
