Finder Impulse switch

Finder impulse switch 20.26.9.024.4000

Manufacturer: Finder
Designation: Impulse switch
Type: 20.26.9.024.4000
Function: Mechanical switch
Mounting type: DIN rail
Width in pitch units: 1
Installation depth: 58.4 mm
Number of contacts as normally open: 2
Control voltage: 24 V
Control voltage type: DC
Rated switching current: 16 A
Supply voltage: 24 V
Voltage type of supply voltage: DC
Max. incandescent lamp load: 2000 W
Max. fluorescent lamp load: 1000 VA
Max. fluorescent lamp load (duo circuit): 1000 VA
Max. fluorescent lamp load (parallel compensated): 1000 VA
Fluorescent lamp load (parallel compensated): 750 VA
Max. switching current (cos phi 0.5): 750 VA
Switching current (cos phi 0.6): 12 A
Suitable for manual operation: Yes

Further details:
Impulse switch for 35 mm rail, 2 NO contacts for 16 A / 250 V AC, contact material AgSnO², max. switching capacity with 230 V AC:
AC switching capacities at 230 V AC:
AC1 4000 VA, AC15 750 VA, incandescent and halogen lamps 2000 W, fluorescent lamps compensated 750 W, fluorescent lamps uncompensated 1000 W, energy-saving lamps 400 W, LED (230 V AC) 400 W, LV halogen lamps or LED with electronic ballast 400 W, LV halogen lamps or LED with electronic ballast 800 W.
Coil data: 24 V DC, 5 W, 105 Ohm, width 17.5 mm, switching sequence: off off / on off / on on, test button and mechanical switch position indicator, relay protection class: IP 20.
EAN: 8012823291277.
