Finder Impulse switch

Finder current impulse switch 20.23.9.012.4000

Manufacturer: Finder
Designation: Current impulse switch
Type: 20.23.9.012.4000
Function: Mechanical switch
Mounting type: DIN rail
Width in units of pitch: 1
Installation depth: 58.4 mm
Number of contacts as NO: 1
Number of contacts as NC: 1
Control voltage 1: 12 V
Control voltage type 1: DC
Frequency of control voltage 1: 0 Hz
Rated switching current: 16 A
Supply voltage: 12 V
Supply voltage type: DC
Max. lamp load: 2000 W
Incandescent lamp load: 2000 W
Max. fluorescent lamp load: 1000 VA
Max. fluorescent lamp load (duo circuit): 1000 VA
Max. fluorescent lamp load (parallel compensated): 1000 VA
Fluorescent lamp load (parallel compensated): 750 VA
Max. switching current (cos phi 0.0): 750 VA
Switching current (cos phi 0.6): 12 A
Suitable for manual operation: Yes

Finder impulse switch 20.23.9.012.4000: further details
Impulse switch for 35 mm rail, 1 NO and 1 NC contact for 16 A / 250 V AC, contact material AgSnO², max. switching capacity at 230 V AC: AC switching capacities at 230 V AC: AC1 4000 VA, AC15 750 VA, incandescent and halogen lamps 2000 W, fluorescent lamps compensated 750 W, fluorescent lamps uncompensated 1000 W, energy-saving lamps 400 W, LED (230 V AC) 400 W, LV halogen lamps or LED with ECG 400 W, LV halogen lamps or LED with CCG 800 W, coil data: 12 V DC, 5 W, 27 Ohm, width 17.5 mm, switching sequence: off on / on off, test button and mechanical switch position indicator, relay protection class: IP 20.
