Eltako Impulse switch

Ratings
BrandMore from Eltako
Delivered between Wed, 25.3. and Fri, 10.4.
Free shipping starting at 50.–

Electric current output2

Product details

Eltako current impulse switch S09-12V

Manufacturer: Eltako
Designation: Current impulse switch 1S 16A 1/250V AC
Type: S09-12V
Function: Other
Mounting type: DIN-rail
Width in units of pitch: 0.5
Installation depth: 55 mm
Number of contacts as normally open: 1
Control voltage 1: 12 V
Control voltage type 1: AC
Frequency of control voltage 1: 50 Hz
Rated breaking current: 16 A
Max. fluorescent lamp load (parallel compensated): 500 VA
Max. switching current (cos phi: 0 VA)
Switching current (cos phi: 0.6): 8 A
Suitable for manual operation: Yes

Eltako current impulse switch S09-12V features manual operation and switch position indication. It has a control power requirement of 5W and is designed for pulse control with a contact spacing of 3 mm. EAN: 4010312104187.

Key specifications

Scope of delivery
250V AC S09-12V, Impulse switch 1S 16A 1
Output current type
AC
Electric current output
8 A
Output voltage
12 V
input voltage
12 V
Number of poles
1x

General information

Item number
17823864
Manufacturer
Eltako
Category
Relays
Manufacturer no.
29100011
Release date
10.12.2021
Sales rank in Category Relays
30 of 24687
External links
Manufacturer's site (de)

Relay properties

input voltage
12 V
Output voltage
12 V
Electric current output
8 A
Output current type
AC
Switching function
Normally open
Number of openers
1x
Number of closers
1x
Number of poles
1x
Max. Switching capacity
0.50 kW

Smart home features

Smart Home
Compatible

Origin

Country of origin
Germany

Voluntary climate contribution

CO₂-Emission
Climate contribution

Scope of delivery

Scope of delivery
250V AC S09-12V, Impulse switch 1S 16A 1

Product dimensions

Length
55 mm
Height
55 mm

30-day right of return
24 Months Warranty (Bring-in)
