Datalogic PowerScan PM9100
1D barcodesMore than 10 pieces in stock at third-party supplier
connector2
Product details
Short Info: Datalogic PowerScan PM9100 - USB Kit - portable barcode scanner with RF (433 MHz)
Manufacturer: Datalogic
Model: PowerScan PM9100
EAN/UPC:
Product Description:
The Datalogic PowerScan PM9100 is a portable barcode scanner that operates and decodes using RF (433 MHz).
General Details:
- Type: Portable barcode scanner
- Color: Black, Yellow
- Localization: Europe
- Barcode Interfaces: RF (433 MHz)
- Minimum Barcode Width: 2.5 mil
- Scan Element Type: Visible laser diode
- Scan Mode: Single Pass
- Skew (Degrees): 70
- Pitch (Degrees): 75
- Print Contrast Signal (PCS): 15%
Decoding Capability:
The scanner can decode a variety of codes, including Code 93, Industrial 2 of 5, Code 39, IATA, ISBN, GS1 DataBar, Code 32, Full ASCII Code 39, Codabar, Code 128, Code 11, Interleaved 2 of 5, Codablock F, Plessey, Standard 2 of 5, MSI, UPC/EAN Additions, Datalogic 2 of 5, Code 39 CIP, Code 4, Code 5 TTL.
Connection Technology:
Wireless
Success Notification:
Beep, LED display
Features:
Protected against electrostatic discharge, Datalogic Three Green Lights (3GL), Datalogic STAR Cordless System
Miscellaneous:
Included Accessories: Cradle
Included Cables: 1 x USB Cable - external
Marking: RoHS, IP65, IEC 62471
Power Supply:
Power Supply Unit: Power adapter
Battery: 1 x Lithium-Ion
Software:
Included Software: Datalogic Aladdin, OPOS/JavaPOS drivers
Dimensions and Weight:
- Width: 7.4 cm
- Depth: 11 cm
- Height: 21.2 cm
Environmental Conditions:
- Minimum Operating Temperature: -20 °C
- Maximum Operating Temperature: 50 °C
- Allowed Humidity during Operation: 0 - 95% (non-condensing)
Drop Specification:
2 m over concrete floor.
Scanner type | Hand-held scanner |
Connections | USB |
Signal transmission | RFID-blocking |
Item number | 17742071 |
Manufacturer | Datalogic |
Category | Barcode scanners |
Manufacturer no. | PM9100-433RBK10 |
Release date | 6.12.2021 |
External links | |
May include power adapter | No |
Colour | Black, Yellow |
Exact colour description | Black, Yellow |
Scanner type | Hand-held scanner |
Barcode Scanner Version | Scanner USB + Cradle Kit |
Barcode Scanner Features | Keyboard inscription |
Connections | USB |
Signal transmission | RFID-blocking |
Protection type (IP code) | IP65 |
Max. Drop height | 2 m |
Scanner functions | 1D barcodes |
Minimum print contrast | 15% |
Stack codes | Codabar/MW7, Code 32, Code 39, Code 93, GS1 DataBar, IATA, ISBN |
Read angle lengthwise max. | 75° |
Read angle cross max. | 70° |
Wireless transmission | Radio Frequency (RF) |
Frequency | 433 MHz |
Battery type | Lithium-Imide |
Country of origin | China |
CO₂ emissions | 251.54 kg |
Climate contribution | CHF 5.98 |
Scope of delivery | Cradle, USB cable - external |
Length | 110 mm |
Width | 74 mm |
Height | 212 mm |
Length | 37.70 cm |
Width | 31.20 cm |
Height | 14.80 cm |
Weight | 2.19 kg |
