Best ABB products in the Residual-current device category
On this page you'll find a ranking of the best ABB products in this category. To give you a quick overview, we've already ranked the most important information about the products for you.
1. ABB Ground fault circuit interrupter
Current: 40A. Number of poles: 2. tripping sensitivity: 30mA. Tripping characteristic: Type A. Series: F202. DIN VDE 0664 part 11, DIN VDE 0664 part 1 // 10.85, EN 61008-2-1. residual current circuit-breaker, series F200. residual current circuit-breaker. 2- or 4-pole. Detect AC residual currents and pulsating DC residual currents. Shock current resistant up to 250A and therefore insensitive to short leakage currents to earth. DIN rail mounting. Signalling contact/auxiliary switch. 1 changeover contact. A maximum of three S2C-S/H6R can be connected in series.
2. ABB Circuit breaker 3 pole
For line protection according to DIN VDE 0641 part 11, 3-pole 230/400 V/AC.
3. ABB S201-D8 Automatic circuit breaker D-Char., 6 kA, 8 A, 1P
ABB ABB S201-D8 Automatic circuit breaker D-Char.
Residual-current device
−21%
only 1 of 3 remaining on sale
CHF18.80 was CHF23.90
ABB S201-D8 Automatic circuit breaker D-Char., 6 kA, 8 A, 1P
4. ABB STOTZ-KONTAKT 2CDS251001R0278 circuit breaker Miniature circuit breaker
ABB STOTZ-KONTAKT ABB 2CDS251001R0278 Miniature circuit breaker (2CDS251001R0278).
Residual-current device
−29%
only 46 of 46 remaining on sale
CHF17.50 was CHF24.60
ABB STOTZ-KONTAKT 2CDS251001R0278 circuit breaker Miniature circuit breaker
5. ABB Automatic circuit breaker
ABB Stotz S&J Automatic Circuit Breaker S203-B40 Manufacturer: ABB Stotz S&J Designation: Automatic Circuit Breaker B,6kA,40A,3P Type: S203-B40 Installation depth: 69 mm Tripping characteristic: B Number of poles (total): 3 Number of fused poles: 3 Rated current: 40 A Rated voltage: 400 V Rated insulation voltage Ui: 440 V Rated impulse withstand voltage Uimp: 4 kV Rated breaking capacity Icn according to EN 60898 at 230 V: 6 kA Voltage type: AC Rated breaking capacity Icn according to EN 60898 at 400 V: 6 kA Rated breaking capacity Icu according to IEC 60947-2 at 230 V: 10 kA Rated breaking capacity Icu according to IEC 60947-2 at 400 V: 20 kA Frequency: 50..60 Hz Energy limitation class: 3 Flush mounting: no Switching neutral: no Overvoltage category: 3 Degree of pollution: 3 Additional devices possible: yes Width in pitch units: 3 Protection class (IP): IP20 Ambient temperature during operation: -25..55 °C Connectable conductor cross-section stranded: 0..25 mm² Connectable conductor cross-section solid: 0..35 mm²ABB Stotz S&J automatic circuit breaker S203-B40: further detailsThe automatic circuit breakers of the S 200 series protect cables and wires against overloads and short circuits in accordance with DIN VDE 0100-430 and DIN VDE 0100-530. They comply with the construction regulations DIN VDE 0641-11 or IEC/EN 60898-1, DIN VDE 0660-101 or IEC/EN60947-2 and UL1077. Their patented connection terminal ensures simple and safe contacting and handling by means of a pressure plate. For better visibility during wiring, the connection opening for conductors is located above the connection opening for the phase rail. Conductor cross-sections of up to 35 mm² can be connected directly to the device via the terminal block with insulation in protection class IP20. The extensive range of accessories offers you everything you need for your installation tasks. Numerous approvals make the S 200 fit for worldwide use. Each unit is subjected to three intensive tests for quality and performance before delivery. , EAN: 4016779469401
6. ABB S200 MCB 16A 3 Pole Type D 6kA
Range = System M Pro
Series = S200
Number of poles = 1
Rated current = 16 A
Tripping characteristic = Type D
AC rated voltage = 253V
DC rated voltage = 72V
Breaking capacity = 6 kA
Length = 88mm
width = 17.5mm
Depth = 75.8mm
Classic & System pro M products cannot be mixed and they have no common accessories. System Pro M series products can only be mounted in new type Protecta distribution boxes, see part no. 539-1553 (typical). Type D, 1-pole, 6 kA - System Pro M. Type D provides a short-circuit response at 10 to 13 times the rated current (but higher than Type C), making it ideal for circuits with higher inrush currents such as motor control and fluorescent lighting in industrial buildings, where faster types often cause inadvertent false tripping. DIN rail mounted In accordance with BS EN 60898 Operating temperature range -25 °C to +55 °C Standard width 17.5 mm Maximum operating voltage: 440 Vac, 60 Vdc.
7. ABB Automatic circuit breaker SH200 type C 10A 6kA
Range = System M Pro
Series = S200
Number of poles = 1
Rated current = 10 A
Tripping characteristic = Type C
AC rated voltage = 440V
DC rated voltage = 60V
Breaking capacity = 6 kA
Length = 85mm
width = 17.5mm
Depth = 69mm
Type C, single pole, 6 kA. Type C provides a short-circuit response at 5 to 10 times the rated current, making it ideal for circuits with higher inrush currents such as motor control and fluorescent lighting in industrial buildings where faster types often lead to accidental false tripping. DIN rail mounted In accordance with BS EN 60898 Operating temperature range -25 °C to +55 °C Standard width 17.5 mm Maximum operating voltage: 440 Vac, 60 Vdc.
8. ABB SMISSLINE circuit breaker
ABB Circuit breaker S451E-C13 13A 1 pole.
Residual-current device
Quantity discount
CHF11.40 per piece for 2 units
ABB SMISSLINE circuit breaker
9. ABB Smissline neutral isolator, up to 63A
ABB Smissline Classic neutral conductor isolator, can be plugged into the right-hand side of automatic machines, connections ≤ 16 mm².
Residual-current device
Quantity discount
CHF7.65 per piece for 3 units
ABB Smissline neutral isolator, up to 63A
10. ABB SN201 MCB, 2P Poles, 16A Curve C
Number of Poles = 2P // Current Rating = 16A // Tripping Characteristics = Type C // Series = SN201 // Mounting Style = DIN Rail Mount.
