Weidmüller Arrester type3 24VAC 27VDC 13A TS35 8449160000

Weidmüller MCZOVPTAZDIODE24VUC surge protection

Manufacturer: Weidmüller
Designation: Surge protection
Type: MCZOVPTAZDIODE24VUC
Rated voltage AC: 24 V
Rated voltage DC: 27 V
Maximum continuous voltage AC: 27 V
Maximum continuous voltage DC: 26 V
Rated leakage current (8/20): 0.5 kA
Rated load current: 13 A
Protection level wire/wire: 65 V
Protection level wire/earth: 130 V
Mounting type: Top-hat rail TH35
Connection 1: Terminal
With remote signalling contact: No
Signalling on device: Without
Explosion-proof version: No
Construction width: 6 mm
Protection class (IP): IP20

Weidmüller MCZOVPTAZDIODE24VUC surge protection: further details
Device for surge protection in information technology and measurement technology. The device should be installed close to the equipment to be protected.
EAN: 4008190128548.
