Warema 1002655

Potential-free switching actuator for controlling drives in the WAREMA climatronic® system. It can switch up to 4 sun protection drives or up to 8 230 V AC consumers (e.g., lighting). The assignment of connected consumers can be done individually or arbitrarily across the 64 available channels. A 230 V supply line to the device and a 4-wire bus connection to the WAREMA climatronic® system are required. The power supply for the products is either 230 V AC or 24 V DC, which is separated by terminal set. The control of consumers (e.g., lighting) is carried out via the bus system through the WAREMA climatronic®. The connection of conventional switches allows for local individual and group operation. To lock individual motors, for example, when a balcony door is open, external window contacts (reed contacts) can be connected to the actuators. The operating logic of the connected local switches is automatically adjusted to the set product of the channel. Typical applications include smaller objects with a low number of actuators (e.g., living areas, conservatories, etc.), but also special circuits (e.g., control of various fan drives). Additionally, it is also possible to switch different circuits through one actuator. Note: An external power supply is required. This is the 4M REG variant.
