Votronic 3336 DC/DC converter DC/DC 1212-45 12V to 12.5V,13V, 13.5V

This VOTRONIC DC-DC converter from the DCDC series enables the safe operation of 12V consumers on 12V electrical systems without the need for a separate battery system. The devices can be operated temporarily with up to 30% overload, allowing them to handle inrush, peak, and starting currents of various consumers. For safety against voltage surges, defective ground lines, etc., galvanic isolation is built between the input and output sides. This ensures proper, independent ground conditions on both sides even with long connection cables, which is particularly useful in large vehicles, containers, roll containers, trailers, etc. Once the DC-DC converters are activated via the ON/OFF control input, which can be triggered by a switching signal, vehicle ignition, or D+, the battery voltage monitoring is also operational (charging detection at the starter battery, undervoltage shutdown). The output voltage is stabilized and smoothed, making it ideal for sensitive consumers. The output voltage can be set to three fixed, stabilized output voltages. In the fourth switch position, the output replicates the height of the input voltage variably. In this operating mode, it is also advantageous to operate consumers that derive additional information from the 12V operating voltage.
