Name: SIEM 5SL6510-7 Miniature circuit breaker 230V 6kA, 1+Npol. C, 1
Brand: Siemens
SKU: 23118660
Price: 16.7 CHF
Availability: InStock

productDetailPageQuery

Siemens

Siemens Circuit Breaker 5SL6510-7

Manufacturer: Siemens
Description: Circuit breaker 230V 6kA 1+N C 10A
Type: 5SL6510-7
Installation depth: 70 mm
Tripping characteristic: C
Number of poles (total): 2
Number of protected poles: 1
Rated current: 10 A
Rated voltage: 230 V
Rated short-circuit capacity Icn according to EN 60898 at 230 V: 6 kA
Voltage type: AC
Rated short-circuit capacity Icn according to EN 60898 at 400 V: 6 kA
Rated short-circuit capacity Icu according to IEC 60947-2 at 230 V: 6 kA
Rated short-circuit capacity Icu according to IEC 60947-2 at 400 V: 6 kA
Frequency: 50 Hz
Energy limitation class: 3
Flush-mounted: no
Switching neutral conductor: yes
Overvoltage category: 3
Pollution degree: 2
Additional devices possible: yes
Width in division units: 2
Protection class (IP): IP20
Ambient temperature during operation: -25 to 45 °C
Connectable conductor cross-section multi-stranded: 0.75 to 25 mm²
Connectable conductor cross-section single-stranded: 0.75 to 25 mm²
Explosion-proof: no

Siemens Circuit Breaker 5SL6510-7: additional details
Circuit breaker 230V 6kA, 1+N-pole, C, 10A.
SENTRON 5SL circuit breakers provide safe short-circuit and overload protection for standard applications in residential and commercial buildings. Tool-free installation and removal of the device. Simple wiring of the supply through the rear-mounted busbar. The 5SL circuit breakers are available in 1-, 2-, 3-, 4-, as well as in 1+N and 3+N-pole versions, along with other special types. The extensive accessories, such as auxiliary switches, allow for versatile expansion of functions. Simply safe with SENTRON protective devices.
