Product details
Current range: 2.8 to 4 A
Number of poles: 3P
Range: Sirius Innovation
Breaking capacity: 100 kA
Connection type: Screw fixing
Operating voltage: 690 V
Length: 90 mm
Width: 45 mm
Depth: 81 mm
Dimensions: 90 x 45 x 81 mm
Series: 3RV1
UL, CSA, IEC947, VDE0990, EN60947. Three pole overload switches - 3RV 10 series. Maximum rated current: 100 A (45 kW at 400 Vac). Rated operating voltage: 690 V. Short circuit proof up to 50 kA at 400 Vac. Maximum switching frequency: 15 operations per hour. Mechanical life: 10^5 operations. Ambient temperature range: -20 to +60 °C. Long-term stability. Manual reset. Can be locked in OFF position.
