Siemens HLS-FUSE INLAY 63A 1000V

63 A
Ratings
BrandMore from Siemens
Delivered between Thu, 11.9. and Fri, 12.9.
Only 1 piece in stock at third-party supplier
Supplied by
free shipping

Product details

Fuse standard: DIN 43620, IEC 60269-2-1, VDE 0636
Fuse size: 0
Current: 63A
Operating voltage: 1000V AC
High breaking capacity: Yes
Total length: 125mm
Designation plate width: 6mm
Housing height: 47mm
Housing width: 30mm
Housing length: 65mm
Application category: aR
Fuse type: HLS

IEC 60269-2 SITOR fuses, 3NE4 series, size 0, type aR. Semiconductor protection fuses operating class aR (partial range semiconductor protection) with blade contacts, for installation in NH fuse bases or load switches. SITOR-NH fuse links are designed for overload and short-circuit protection of cables, wires, and busbars, as well as for the protection of semiconductors.

Key specifications

Item number
10314473

General information

Manufacturer
Siemens
Category
Fuses
Manufacturer no.
3NE4118
Release date
15.1.2019
External links
Manufacturer's site (de)

Backup Features

Fuse type
NH-DIN fuse
Nominal current
63 A
breaking capacity
100000 A
Nominal voltage
1000 V
voltage type
AC/DC

Origin

Country of origin
Greece

Sustainability

Manufacturer commitment
RE100, SBTi

Voluntary climate contribution

Manufacturer compensation
According to RE100, the manufacturer Siemens fully compensates for its energy consumption, leading to a reduction in emissions.
CO₂-Emission
Climate contribution

Scope of delivery

Items per sales unit
1 pcs.

Product dimensions

Width
100 mm
Length
135 mm
Height
70 mm
