Product details
Siemens Dig.Industr. Residual Current Circuit Breaker 5SV3644-4KK14
Manufacturer: Siemens Dig.Industr.
Designation: Residual Current Circuit Breaker Type B+, 300 mA, 40 A
Type: 5SV3644-4KK14
Number of Poles: 4
Rated Voltage: 400 V
Rated Current: 40 A
Rated Residual Current: 0.3 A
Mounting Type: DIN Rail
Residual Current Type: B+
Selective Type: No
Short-time Delayed Type: Yes
Short-circuit Strength (Icw): 10 kA
Surge Current Strength: 3 kA
Voltage Type: AC
With Locking Device: Yes
Frequency: 50 Hz
Additional Devices Possible: Yes
Protection Class (IP): IP20
Width in Division Units: 4
Installation Depth: 70 mm
Ambient Temperature During Operation: -25..45 °C
Connectable Conductor Cross-section Multi-stranded: 0.75..35 mm²
Connectable Conductor Cross-section Single-stranded: 0.75..35 mm²
Explosion Protected: No
Further Details: Residual Current Circuit Breaker, 4-pole, Type B+, short-time delayed, In: 40 A, 300 mA, Un AC: 400 V.
The SENTRON 5SV3 residual current circuit breakers provide comprehensive protection for people and property against electric shock. They ensure reliable safety during installation through the standard included gripping and touch protection. With the convenient slider manual operation, you can easily detach the residual current circuit breakers from the DIN rail or busbar system without tools. The data matrix code on the device provides quick access to all technical data in the Siemens Industry Online Support App. The SENTRON protective devices can be expanded with a wide range of functions using the consistent accessories from the system modular kit. Optimal technology for your safety - only from Siemens.
EAN: 4001869549194.
