Siemens Circuit breaker UC B 32A 1+N 230V 5SL4532-6

Ratings
BrandMore from Siemens
Delivered between Fri, 15.8. and Sat, 6.9.

Product details

Siemens Dig.Industr. Circuit Breaker 5SL4532-6

Manufacturer: Siemens Dig.Industr.
Designation: Circuit breaker 230V, 10kA, 1+N, 32A
Type: 5SL4532-6
Installation depth: 70 mm
Tripping characteristic: B
Number of poles (total): 2
Number of protected poles: 1
Rated current: 32 A
Rated voltage: 230 V
Rated short-circuit capacity Icn according to EN 60898 at 230 V: 10 kA
Voltage type: AC
Rated short-circuit capacity Icn according to EN 60898 at 400 V: 10 kA
Rated short-circuit capacity Icu according to IEC 60947-2 at 230 V: 10 kA
Rated short-circuit capacity Icu according to IEC 60947-2 at 400 V: 10 kA
Frequency: 50 Hz
Energy limitation class: 3
Flush-mounted: no
Switching neutral conductor: yes
Overvoltage category: 3
Degree of pollution: 2
Additional devices possible: yes
Width in division units: 2
Protection class (IP): IP20
Ambient temperature during operation: -25..55 °C
Connectable conductor cross-section multi-stranded: 0.75..25 mm²
Connectable conductor cross-section single-stranded: 0.75..25 mm²
Explosion-proof: no

Siemens Dig.Industr. Circuit Breaker 5SL4532-6: additional details
Circuit breaker 230V 10kA, 1+N-pole, B, 32A
SENTRON 5SL circuit breakers provide safe short-circuit and overload protection for standard applications in residential and commercial buildings. Tool-free installation and removal of the device. Easy wiring of the supply through the rear-mounted busbar. The 5SL circuit breakers are available in 1-, 2-, 3-, 4-, as well as in 1+N and 3+N pole configurations, along with other special types. The extensive accessories, such as auxiliary switches, allow for versatile expansion of functions. Simply safe with SENTRON protective devices.

Key specifications

Circuit breaker type
Miniature circuit breaker
Length
70 mm
Width
2 mm
mounting style
Built-in
number of poles
1
Item number
32371933

General information

Manufacturer
Siemens
Category
Residual-current device
Manufacturer no.
5SL4532-6
Release date
7.12.2022

Circuit Breaker Features

Circuit breaker type
Miniature circuit breaker
mounting style
Built-in
number of poles
1
Tripping characteristic
B
Rated current
32 A
Rated voltage
230 V
voltage type
AC
Protection type (IP code)
IP20

Origin

Country of origin
Romania

Sustainability

Manufacturer commitment
RE100, SBTi

Voluntary climate contribution

Manufacturer compensation
According to RE100, the manufacturer Siemens fully compensates for its energy consumption, leading to a reduction in emissions.
CO₂-Emission
Climate contribution

Scope of delivery

Items per sales unit
1 Piece

Product dimensions

Length
70 mm
Width
2 mm

30-day right of return if unopened
24 Months Warranty (Bring-in)
