Siemens Ceramic fuse MT 12A 500V AC 10x38mm 3NW6006-1

Siemens Dig.Industr. Cylinder Fuse 3NW6006-1

Manufacturer: Siemens Dig.Industr.
Description: Cylinder fuse 500V, 12A
Type: 3NW6006-1
Size: 10x38 mm
Voltage type: AC
Rated current: 12 A
Rated voltage: 500 V
Operating class: gL/gG (Full-range line protection/Full-range device protection)
Operating frequency: 45..62 Hz
Tripping characteristic: other
Cut-off capacity: 100 kA
Power loss at rated current: 1.4 W

Siemens Dig.Industr. Cylinder Fuse 3NW6006-1: additional details SENTRON, cylinder fuse insert, 10x38 mm, 12 A, gG, Un AC: 500 V. SENTRON cylinder fuse system for selective plant protection. Siemens cylinder fuse inserts and fuse holders are suitable for use in industrial plants. They are standard in Europe and have been tested and approved as fuse disconnectors, but are not intended for switching under load. For switching under load, Siemens offers a comprehensive portfolio, such as 3KF. The Siemens cylinder fuse systems are characterized by:

1. Compliance with standards IEC 60269-1, -2, and -3.
2. Compliance with standard UL 512.
3. Quick fuse replacement due to space for spare fuses in the insert.
4. Fast identification of the triggered fuse through a blinking LED in case of tripping.

EAN: 4001869061511.
