Siemens ALPHA 630 Patch panel IP43 protection class.

Ratings
BrandMore from Siemens
Delivered between Wed, 22.10. and Fri, 7.11.
free shipping

Product details

Siemens Digital Industry ALPHA 630, Distribution Board 8GK1382-0KK22

Manufacturer: Siemens Digital Industry
Designation: ALPHA 630, Distribution Board
IP Protection: IP43
Protection Class: Type 8GK1382-0KK22
Mounting Type: Other
Type of Cover: Lid
Lid Design: Without
Type of Door: Single
Transparent Lid/Door: No
With Lock: Yes
Rated Current (In): 630 A
Height: 350 mm
Width: 550 mm
Depth: 210 mm
Installation Depth: 210 mm
Internal Depth: 210 mm
Material Thickness of Door/Lid: 0.75 mm
Color: Gray
RAL Number: 7035
Number of Openings for Flange Plates: 4
Mounting Option: Yes
Housing Material: Steel
Surface Protection: Powder Coated
With Mounting Plate: No
Suitable for Outdoor Use: No
Suitable for Lightning Protection: Yes
Protection Type (IP): IP43
Protection Type (NEMA): Other
Protection Class: I
Impact Resistance: IK09
Function Maintenance: Without

The ALPHA installation distribution boards are a complete system of wall and floor-mounted distribution boards for the installation of devices up to 1250 A. The ALPHA distribution systems are tested according to IEC 61439. Due to the modular design and a common platform structure, device-specific installation kits can be integrated into various distribution board variants. This facilitates planning and installation. The equipment is customized and project-specific. The configuration software SIMARIS configuration supports everything from planning to documentation of energy distribution and installation distribution boards. The ALPHA distribution systems are available in a wide range of designs and many special colors. The doors can be made of glass or steel. ALPHA - the system concept matters.
EAN: 4001869304373.

Key specifications

Protection type (IP code)
IP43
Length
210 mm
Width
550 mm
Height
350 mm
Item number
13050319

General information

Manufacturer
Siemens
Category
Wiring closet technology
Manufacturer no.
8GK13820KK22
Release date
7.4.2020

Colour

Colour
Grey
Exact colour description
Grey ral 7035

Material

Material group
Metal
Material
Steel

Distribution cabinet technology Features

Nominal current
630 A
Protection type (IP code)
IP43
Divisions
4 x

Origin

Country of origin
Germany

Sustainability

Manufacturer commitment
RE100, SBTi

Voluntary climate contribution

Manufacturer compensation
According to RE100, the manufacturer Siemens fully compensates for its energy consumption, leading to a reduction in emissions.
CO₂-Emission
Climate contribution

Scope of delivery

Items per sales unit
1 pcs.

Product dimensions

Length
210 mm
Width
550 mm
Height
350 mm
Depth
210 mm
