SFA Saniaccess Waterpompunit Saniaccess2

The Sanibroyeur Saniaccess 2 is a wastewater pumping unit designed for the processing of greywater and rainwater. This compact waste grinding system measures 424 mm in width, 166 mm in depth, and 330 mm in height, allowing for installation behind toilet bowls even in limited spaces. The unit operates on single-phase 230 V power with a nominal voltage of 230 V and comes with a 1.2 m long power cable. It achieves a volumetric flow rate of 2.7 m³/h at its best efficiency point, with a maximum lift height of 5 m and a maximum flow rate of 5 m³/h. The pump features an 8.8 l polypropylene (PP-H) tank and a cutting mechanism for processing solids. The motor delivers an output power of 300 W with an input consumption of 400 W and operates at 2800 revolutions per minute. Connection options include two inlet connections with plug-in fittings and an outlet connection with a clamp fitting at a diameter of DN 32. The toilet connection diameter is 100 mm. The pump housing is made of fiber-reinforced plastic, while the impeller is constructed from glass-fiber-reinforced polypropylene (PP-GF). The unit includes ventilation, non-return valve, and backflow prevention functions. It can process solid particles up to a maximum size of 5 mm and operates continuously within a medium temperature range of 35 °C. The ambient operating conditions range from 5 °C to 40 °C. The pump has an IP44 protection rating and an insulation class F according to IEC standards. This system is designed for sewage applications and includes standard installation behind toilet bowls with possible connections to toilets and sinks. The compact design ensures easy accessibility while providing reliable performance for wastewater management applications.
